Question

Rewrite the following integral in spherical coordinates.​

Answer 1

In cylindrical coordinates, we have $r^2=x^2+y^2$, so that

$z = \pm \sqrt{2-r^2} = \pm \sqrt{2-x^2-y^2}$

correspond to the upper and lower halves of a sphere with radius $\sqrt2$. In spherical coordinates, this sphere is $\rho=\sqrt2$.

$1 \le r \le \sqrt2$ means our region is between two cylinders with radius 1 and $\sqrt2$. In spherical coordinates, the inner cylinder has equation

$x^2+y^2 = 1 \implies \rho^2\cos^2(\theta) \sin^2(\phi) + \rho^2\sin^2(\theta) \sin^2(\phi) = \rho^2 \sin^2(\phi) = 1 \\\\ \implies \rho^2 = \csc^2(\phi) \\\\ \implies \rho = \csc(\phi)$

This cylinder meets the sphere when

$x^2 + y^2 + z^2 = 1 + z^2 = 2 \implies z^2 = 1 \\\\ \implies \rho^2 \cos^2(\phi) = 1 \\\\ \implies \rho^2 = \sec^2(\phi) \\\\ \implies \rho = \sec(\phi)$

which occurs at

$\csc(\phi) = \sec(\phi) \implies \tan(\phi) = 1 \implies \phi = \dfrac\pi4+n\pi$

where $n\in\Bbb Z$. Then $\frac\pi4\le\phi\le\frac{3\pi}4$.

The volume element transforms to

$dx\,dy\,dz = r\,dr\,d\theta\,dz = \rho^2 \sin(\phi) \, d\rho \, d\theta \, d\phi$

Putting everything together, we have

$\displaystyle \int_0^{2\pi} \int_1^{\sqrt2} \int_{-\sqrt{2-r^2}}^{\sqrt{2-r^2}} r \, dz \, dr \, d\theta = \boxed{\int_0^{2\pi} \int_{\pi/4}^{3\pi/4} \int_{\csc(\phi)}^{\sqrt2} \rho^2 \sin(\phi) \, d\rho \, d\phi \, d\theta} = \frac{4\pi}3$
