Answer:
Hi, for this exercise we have two laws to bear in mind:
Morgan's laws
NOT(А).NOT(В) = NOT(A) + NOT (B)
NOT(A) + NOT (B) = NOT(А).NOT(В)
And the table of the Nand
INPUT OUTPUT
A B A NAND B
0 0 1
0 1 1
1 0 1
1 1 0
Let's start!
a.
Input OUTPUT
A A A NAND A
1 1 0
0 0 1
b.
Input OUTPUT
A B (A NAND B ) NAND (A NAND B )
0 0 0
0 1 0
1 0 0
1 1 1
C.
Input OUTPUT
A B (A NAND A ) NAND (B NAND B )
0 0 0
0 1 1
1 0 1
1 1 1
Explanation:
In the first one, we only need one input in this case A and comparing with the truth table we have the not gate
In the second case, we have to negate the AND an as we know how to build a not, we only have to make a nand in the two inputs (A, B) and the make another nand with that output.
In the third case we have that the OR is A + B and we know in base of the morgan's law that:
A + B = NOT(NOT(А).NOT(В))
So, we have to negate the two inputs and after make nand with the two inputs negated.
I hope it's help you.
I think hibernate is sort of like sleep mode. It puts your computer on low battery, but it's not turn off. And some unsaved information doesn't get erase.
Answer:
Apply an entrance effect, and then set it to By letter in the Effect Options dialog box.
Explanation:
PowerPoint application can be defined as a software application or program designed and developed by Microsoft, to avail users the ability to create various slides containing textual and multimedia informations that can be used during a presentation. Some of the features available on Microsoft PowerPoint are narrations, transition effects, custom slideshows, animation effects, formatting options etc.
To format an image on PowerPoint, you can either use the Artistic Effects or Picture Effects.
Some of the features available on Microsoft PowerPoint are narrations, transition effects, custom slideshows, animation effects, formatting options etc.
Basically, the views that are available on the Microsoft PowerPoint application includes;
1. Slide Sorter.
2. Notes Page.
3. Reading Pane.
4. Presenter view.
Using a custom animation effect, in order to make text appear on a slide letter by letter, you should apply an entrance effect, and then set it to By letter in the Effect Options dialog box.
The opportunity cost is the full cost of the trip
Answer:
The description for the given question is described in the explanation section below.
Explanation:
a...
interface Shape
{
public double getArea(); // creating a function
public double getPerimeter(); // creating a function
}
b and c...
- I preferred Interface although abstract classes are being used when children's classes associate certain aspect methods and variables and because all classes represent a certain method throughout the specific solution, not instance variables, it would be easier to construct an interface.
- Almost all of the period interfaces are favored because they have multiple inheritance capabilities.
