Answer:
- A = 48°
- B = 115°
- C = 115°
- D = 67°
- E = 48°
Step-by-step explanation:
A and the angle marked 48° are vertical angles, hence congruent.
A = 48°
B is part of a linear pair with the angle marked 65°, so it is supplementary to that angle.
B = 115°
C is an alternate interior angle with angle B, so is congruent.
C = 115°
D is a vertical angle with the one marked 67°, so is congruent.
D = 67°
E is an alternate exterior angle with the one marked 48°, so is congruent. It is also a corresponding angle with A, so congruent to that as well.
E = 48°
