Question

Graph the polygon and its image after a dilation centered at C(1,1)

Answer 1

Now we proceed to present the graphs of the polygon and its image with the help of a graphing tool. The original polygon is highlighted in red and the image is highlighted in blue.

DIlations are defined by the follwing operation:

$P'(x,y) = O(x,y) + k\cdot [P(x,y)-O(x,y)]$ (1)

Where:

• $O(x,y)$ - Center of dilation.
• $k$ - Dilation factor.
• $P(x,y)$ - Original point of the polygon.
• $P'(x,y)$ - Dilated point of the polygon.

If we know that $O(x,y) = (1,1)$, $k = 0.5$, $J(x,y) = (3,1)$, $K(x,y) = (5, -3)$, $L(x,y) = (5,5)$ and $M(x,y) = (3,7)$, then the coordinates of the new polygon are:

$J'(x,y) = (1,1) + 0.5\cdot [(3,1)-(1,1)]$

$J'(x,y) = (1,1)+0.5\cdot (2,0)$

$J'(x,y) = (1,1) +(1,0)$

$J'(x,y) = (2,1)$

$K'(x,y) = (1,1) + 0.5\cdot [(5,-3)-(1,1)]$

$K'(x,y) = (1,1) +0.5\cdot (4,-4)$

$K'(x,y) = (1,1) +(2,-2)$

$K'(x,y) = (3,-1)$

$L'(x,y) = (1,1) + 0.5\cdot [(5,5)-(1,1)]$

$L'(x,y) = (1,1) + 0.5\cdot (4,4)$

$L'(x,y) = (1,1) + (2,2)$

$L'(x,y) = (3,3)$

$M'(x,y) = (1,1) + 0.5\cdot [(3,7)-(1,1)]$

$M'(x,y) = (1,1) +0.5\cdot (2,6)$

$M'(x,y) = (1,1) +(1,3)$

$M'(x,y) = (2,4)$

Now we proceed to present the graphs of the polygon and its image with the help of a graphing tool. The original polygon is highlighted in red and the image is highlighted in blue.
