Answer:
(a) Rate of heat transfer = 34.65 W/m
(b) quality of outlet of pipe x = 0.967
(c) Temperature of outer surface of insulation, T₂ = U1.157°C
Yes it is safe to touch, (But gentle touch)
Explanation:
Detailed explanation is given in the attach document.
Answer:
The rate of cell metabolism is limited by mass transfer since the value of maximum cell concentration obtained (38 g/l) is lower than 50 g l-1, the value planed.
Explanation:
Data
<u>kLa</u> = 0.17/s
<u>Solubility of oxygen</u> = 8 × 10^-3 kg / m^3
<u>The maximum specific oxygen uptake rate </u>= 4 mmol O2 / g h.
<u>Concentration of oxygen</u> = 0.5 × 10^-3 kg/ m^3
<u>**The maximum cell density</u> = 50 g/l
___________________
The calculated maximum cell concentration:
xmax= kLa · CAL*/ qo
CAL* is the solubility of oxygen in the broth and qo is the specific oxygen uptake rate
Replacing the data given
xmax= ( 0.17/s ) · (8 × 10^-3 kg / m^3) / 4 mmol O2 / g h
4 mmol O2 / g h to kg O2/ g s
= 3.56 x 10^-3 kg O2/ g s
So then,
xmax= ( 0.17/s ) · (8 × 10^-3 kg / m^3) / 3.56 x 10^-3 o kg O2/ g s
xmax= 3. 8 x 10^4 g/ m^3 = 38 g/l
_____________________
