Consider incompressible flow in a circular channel. Derive general expressions for Reynolds number in terms of (a) volume flow r

Georgia [21]

Answer:

a) $Re = \frac{4\cdot \rho \cdot Q}{\pi\cdot \mu\cdot D}$ , b) $Re = \frac{4\cdot \dot m}{\pi\cdot \mu\cdot D}$ , c) 1600

Explanation:

a) The Reynolds Number is modelled after the following formula:

$Re = \frac{\rho \cdot v \cdot D}{\mu}$

Where:

$\rho$ - Fluid density.

$\mu$ - Dynamics viscosity.

$D$ - Diameter of the tube.

$v$ - Fluid speed.

The formula can be expanded as follows:

$Re = \frac{\rho \cdot \frac{4Q}{\pi\cdot D^{2}}\cdot D }{\mu}$

$Re = \frac{4\cdot \rho \cdot Q}{\pi\cdot \mu\cdot D}$

b) The Reynolds Number has this alternative form:

$Re = \frac{4\cdot \dot m}{\pi\cdot \mu\cdot D}$

c) Since the diameter is the same than original tube, the Reynolds number is 1600.

8 0

3 years ago

An instance of the stable marriage problem has a unique stable matching if and only if the version of the Gale-Shapely algorithm

inysia [295]

Answer: True

Explanation:

The statement by Gale-Shapely algorithm is true where the male proposes and the version where female proposes both are correct meaning that altogether it is true. This is applicable when both yield the exact same match.

6 0

3 years ago

Write a program that reads a list of words. Then, the program outputs those words and their frequencies. The input begins with a

Romashka [77]

Answer:

import java.util.HashMap;

import java.util.Map;

import java.util.Scanner;

public class FrequencyOfWords

{

public static void main(String[] args)

{

Scanner in = new Scanner(System.in);

System.out.println("Enter the integer indicating the number of words");

int n = in.nextInt();

System.out.println("Enter the string");

String[] words = new String[n];

for(int i = 0; i < n; ++i)

{

words[i] = in.next();

}

Map<String, Integer> map = new HashMap<>();

for(int i = 0; i < n; ++i)

{

if(!map.containsKey(words[i]))

{

map.put(words[i], 0);

}

map.put(words[i], map.get(words[i])+1);

}

for(Map.Entry<String, Integer> entry : map.entrySet())

{

System.out.println(entry.getKey() + " " + entry.getValue());

}

7 0

4 years ago

Your manager has asked you to research and recommend a writing guide that examiners in your digital forensics company can use fo

vivado [14]

Answer:

Kindly Check the explanation

Explanation:

Report

A Report is a way to present the forensic examination result in front of judge. A report contains warrants, all affidavits issued for arrest, expenses occur during forensic test and lists of evidence. Apart from evidence a report also contains expert opinions.

Guidelines

These are the set of rules and written statement which are used to present the important information in a structured and clear format. The main motive behind to define the guidelines is to achieve standardization in the reports. It also improves the readability of the report.

Guidelines for report

Abstract:

Each report must contain an abstract of the report which gives the brief review about the report. It came at the starting of the report. The main motive behind to give abstract is to give brief about report to someone in a very less time. The size of abstract must not be more than one page.

Index:

Each report must contain an index which display's which content is available at which page of report. The content of index must be appropriate and clear so that the reader will not get confuse.

Format of report:

The formatting of report is also one of the essential parts of the guidelines. It makes the report attractive and also due to this reader not gets bored while reading the report. The guidelines regarding layout of report are as follow:

1. Use time roman font and 12 font size as a default font to explain anything in the report.

2. The explanation must be justified

3. As possible divide the long paragraph. if possible explain in points.

4. The page must have border on all sides

5. Each pages must have numbering and footer

Rules for grammar:

1. The language of the report must be simple and clear. So that everyone can understand it easily.

2. Avoid repeating same sentence or word again and again.

3. Use active instead of passive voice, in order to give importance to doer.

4. Write expressions between commas.

5. Avoid spelling mistakes in report which also make wrong impact.

6. As possible give heading or subheading to material or explanation which must be accurate.

7. Explain, new or difficult words used in the report.

8. What ever written in the report must be through the point and accurate on bases of fact.

Body of report:

The body of the report referred to as a content written inside the report. In order to write an impressive report, it must include all these things:

1. Avoid use of hypothetical question, if still hypothetical question arises it must be bases on factual evidence.

2. Add all the affidavits and warrants in the report issued for search and arrest.

3. The cost money expenses while solving the case.

4. The expert opinion which must be bases on knowledge or previously declare case results.

5. The list of people and evidence which are collected and interrogative during the investigation.

6. If investigation is further going on than write the area in which the investigation further goes on and also mention when the investigation get complete.

Forensic software used:

A short must be given about the software used in the investigation. The result generated by the software must also be pasted in that report. It is more good if attach the snap shot of the result. Add any previous case result in which the same software result is taken as evidence, in order to justify that the result generated by the software is true. Some of forensic softwares are FTK, ProDiscover, Hexworkshop. The result of these softwares must be heighted so that everyone can notice it.

Conclusion:

The conclusion must be given at the end of report to tell according him what result came after investigation. In conclusion also write on which basis the result concludes. There must be strong behind the conclusion.

References:

In Reference write all the cases, thesis, books which an investigator followed to solve the current case. In addition if they referred any internet article. They can also write the website name where that article lies. In short can say that write everything where they got an idea which is helpful in solving the case.

8 0

3 years ago

Consider a cubic crystal with the lattice constant a. Complete the parts (a)-(c) below. (a) Sketch the crystallographic planes w

Anna [14]

Answer:

(a) See attachment

(b) The two planes are parallel because the intercepts for plane [220] are X = 0,5 and Y = 0,5 and for plane [110] are X = 1 and Y = 1. When the planes are drawn, they keep the same slope in a 2D plane.

(c) $d = \frac{a}{\sqrt{h^{2} + k^{2} + l^{2}}} = \frac{1}{\sqrt{2}} = 0,707$

Explanation:

(a) To determine the intercepts for an specific set of Miller indices, the reciprocal intercepts are taken as follows:

For [110]

$X = \frac{1}{1} = 1; Y = \frac{1}{1} = 1; Z = \frac{1}{0} = \inf.$

For [220]

$X = \frac{1}{2} = 0,5;Y = \frac{1}{2} = 0,5;Z = \frac{1}{0} = \inf.$

The drawn of the planes is shown in the attachments.

(b) Considering the planes as two sets of 2D straight lines with no intersection to Z axis, then the slope for these two sets are:

For (1,1):

$K_1 = \frac{1}{1} = 1$

For (0.5, 0.5):

$K_2 = \frac{0.5}{0.5} = 1$

As shown above, the slopes are exactly equal, then, the two straight lines are considered parallel and for instance, the two planes are parallel also.

(c) To calculate the d-spacing between these two planes, the distance is calculated as follows:

The Miller indices are already given in the statement. Then, the distance is:

$\frac{1}{d^{2}} = \frac{h^{2} + k^{2} + l^{2}}{a^{2}}$

$d = \frac{a}{\sqrt{h^{2} + k^{2} + l^{2}}} = \frac{1}{\sqrt{2}} = 0,707$

7 0
