Answer:
See explaination
Explanation:
1) As Evidence we just need to observe the nernst equation,
E = E0 + 2.303 RT / nF log QR
E = cell potential
E0 = Standard cell potential
R = Universal gas constant 8.314 J/K Mol
n = Valency of ion
F = faradays constant 96485 C/ mol
T = temperature in Kelvin
QR = Reaction quocient
If we plot a graph between E and Concentration of ion , We get a straight line according to the equation y = mx + C. that is the nernst equation is in the form of equation of a straight line.
E = E0 + 2.303 RT / nF log QR
Here the slope will be 2.303 RT / nF.
That is if we are measuring the electrode potential at a constant temperature , the only factor which affects the slope will be the the charge of ions 'n'. If n is same for all the ions used the slope of natural logaritham plot wil be same.
if n = 1, at room temperature ( 273 + 25 = 298 K)
2.303 * 8.134 * 298 / 1 * 96486 = 0.0591
Thus it can be concluded that the slope of natural logarithm plot will be same for all ions of the same charge.
2) The Zn metal undergo Oxidation,
Zn(s) \rightarrow Zn2+ (Aq) + 2 e-
Copper undergo Reduction
Cu2+ (Aq)+ 2 e-\rightarrow Cu (s)
The standard electrode potential for the reaction is 1.10 V
Here what happens to Zinc is dissolution into the solution , that is oxidation and what happens at copper is deposition. As Zinc ions goes into the solution , accumulation of Zinc ions around the zinc electrode takes place. ant the electron realeased into the solution reaches to the copper solution through the wire connected between them. copper ions accepts the electron and turns into copper atom (Reduction) and gets deposited at the copper electrode. This electron flow is the current generated.
As copper ions gets reduced and deposits on the copper electrode the copper ions in the solution decreases. Ultimately a situation comes where the zn ions dissolution stops because the zn ions surrownding the anode repells the zn electrode and oxidation stops. At the cathode the absence of cu2+ at cathode electrode interface stops the deposition of at copper electrode also. In short the oxidation and reduction reactions stops . This means that the cell battery power is all used up. A battrery consist of galvanic cell. batteries stores energy in chemical form and deliver it as electrical energy through electrochemical reaction as explained above. when half reactions stops in the battery no current flow takes place and battery stops.
