"How did your current and voltage measurements differ between the series and parallel circuits you created

Physics

1 answer:

irakobra [83]3 years ago

4 0

Answer:

Series circuit:

The voltage that is measured across the circuit is different.

The current measured in a series circuit remains the same at all points in the circuit.

Parallel circuit:

The current measured across each resistor varies

The voltage measured across a parallel circuit will remain the same

Explanation:

Series and parallel circuits behave differently when it comes to the circulation of current and the interaction with a potential difference.

In a series circuit, the resistances are connected end to end. As a result, the voltage that is measured across the circuit is different once resistance is encountered. However, the current measured in a series circuit remains the same at all points in the circuit.

A parallel circuit behaves in an exactly opposite manner to the series circuit. In a parallel circuit, the resistances are connected side by side. As a result of this, the current measured across each resistor varies as there are circuit branches through which electric current can flow into. On the other hand, the voltage measured across a parallel circuit will remain the same
