A segment of wire of total length 3.0 m carries a 15-A current and is formed into a semicircle. Determine the magnitude of the m

agnetic field at the center of the circle along which the wire is placed.

1 answer:

miskamm [114]3 years ago

6 0

Answer:

4.9x10^-6T

Explanation:

See attached file

You might be interested in

The sun's energy is stored in fossil fuels. true or false.

Scilla [17]

Yes,suns original energy are still stored at the bonds of fossils in which they taken long,long time ago and these fossils powered now industries,fuel for vehicles.In those chemical bonds holds much energy packed together for centuries.

8 0

3 years ago

Yanka [14]

C it reduces the amount of useful work done on objects move it up the ramp

8 0

3 years ago

Field lines point straight out from all sides of an object. Which statement best describes the object?

Mashcka [7]

It is positively charged.

8 0

3 years ago

Read 2 more answers

A ski lift carries people along a 220-meter cable up the side of a mountain. Riders are lifted a total of 110 meters in elevatio

jeka94

The ideal mechanical advantage (IMA) can be determined by the following equation:

IMA= Input distance/Output distance

The Input distance and Output distance are:

Input distance=220 meters

Output distance=110 meters

When you substitute in the equation of the ideal mechanical advantage (IMA), you obtain:

IMA= Input distance/Output distance

IMA= 220 meters/110 meters

IMA=2

3 0

3 years ago

A wheel with moment of inertia 25 kg. m2 and angular velocity 10 rad/s begins to speed up, with angular acceleration 15 rad/sec2

Pani-rosa [81]

Answer:

(A) Angular speed 40 rad/sec

Rotation = 50 rad

(b) 37812.5 J

Explanation:

We have given moment of inertia of the wheel $I=25kgm^2$

Initial angular velocity of the wheel $\omega _0=10rad/sec$

Angular acceleration $\alpha =15rad/sec^2$

(a) We know that $\omega =\omega _0+\alpha t$

We have given t = 2 sec

So $\omega =10+15\times 2=40rad/sec$

Now $\Theta =\omega _0t+\frac{1}{2}\alpha t^2=10\times 2+\frac{1}{2}\times 15\times 2^2=50rad$

(b) After 3 sec $\omega =10+15\times 3=55rad/sec$

We know that kinetic energy is given by $Ke=\frac{1}{2}I\omega ^2=\frac{1}{2}\times 25\times 55^2=37812.5J$

7 0

3 years ago
