Kamila [148]
4 years ago
14

At one point in the rescue operation, breakdown vehicle A is exerting a force of 4000 N and breakdown vehicle B is exerting a fo

rce of 2000 N.(i) Using a scale of 1 cm = 500 N, make a scale drawing to show the resultant force on the truck. (ii) Use your diagram to find the magnitude and direction of the resultant force on the truck.

Physics
1 answer:
lukranit [14]4 years ago
8 0

Answer:

1.) Magnitude = 5596 N

2.) Direction = 60 degrees

Explanation: You are given that the breakdown vehicle A is exerting a force of 4000 N at angle 45 degree to the vertical and breakdown vehicle B is exerting a force of 2000 N

Let us resolve the two forces into X and Y component

Sum of the forces in the X - component will be 4000 × cos 45 = 2828.43 N

Sum of the forces in the Y - component will be 2000 + ( 4000 × sin 45 )

= 2000 + 2828.43

= 4828.43 N

The resultant force R will be

R = sqrt ( X^2 + Y^2 )

Substitutes the forces at X component and Y component into the formula

R = sqrt ( 2828.43^2 + 4828.43^2 )

R = sqrt ( 31313752.53 )

R = 5595.87 N

The direction will be

Tan Ø = Y/X

Substitute Y and X into the formula

Tan Ø = 4828.43 / 2828.43

Tan Ø = 1.707106

Ø = tan^-1( 1.707106 )

Ø = 59.64 degree

Therefore, approximately, the magnitude and direction of the resultant force on the truck are 5596 N and 60 degree respectively.

You might be interested in
A- what constant acceleration, in SI units, must a car have to gofrom zero to 60 mph in 10 s?
umka2103 [35]

Answer:

(a) 0.017m/s^2

(b) 17/100,000

(c) 0.17m, 0.558ft

Explanation:

(a) speed = 60mph = 60m/1h × 1h/3600s = 0.017m/s, time = 10s

Acceleration (a) = speed ÷ time = 0.017m/s ÷ 10s = 0.0017m/s^2

(b) g = 9.8m/s^2, a = 0.0017m/s^2

a/g = 0.0017/9.8 = 0.00017 = 17/100,000

(c) Distance = speed × time = 0.017m/s × 10s = 0.17m

Distance in foot = 0.17 × 3.2808ft = 0.558ft

3 0
3 years ago
Read 2 more answers
PLEASE GUYS I REALLY NEED HELP ASAP. THIS IS SO IMPORTANT, I AM EVEN WILLING TO PAY FOR REAL.
malfutka [58]
 <span>The bending of light rays by sun is twice in Einstein's theory as in Newton's theory of gravitation. Einstein's theory was verified by Eddington during the solar eclipse in 1919

Also observed precession of aphelion of mercury completely explained by Einstein's theory but not by Newtonian gravity</span>
3 0
3 years ago
Two identical vertical springs S1 and S2 have masses m1 = 400 g and m2 = 800 g attached to them. If m1 causes spring S1 to stret
OlgaM077 [116]

Answer:

potential energy = mgh

= 400÷1000 × 10× 4÷100

= 0.4 × 10 × 0.04

=4/10 ×10×4/100

= 4/10 × 4/10

=16/100

= 0.16 joules

m1 (400) stretches 4cm

m1 (100g) stretches 1cm

so, m2(800g) stretches 8 cm

potential energy of m2 = mgh

= 800/1000 ×10×8/100

= 0.8 × 0.8

=8/10 ×8/10

= 64/100

=0.64 joules

Ratio of s1 to s2

16/100 ÷ 64/100

= 1:4 ( answer)

6 0
2 years ago
Is a neutron star also a black hole?
coldgirl [10]

No.  A neutron star is the weird remains of a star that blew its outer layers off
in a nova event, and then had enough mass left so that gravity crushed its
electrons into its protons, and then what was left of it shrank down to a sphere
of unimaginably dense neutron soup.  But it didn't have enough mass to go
any farther than that.

A black hole is the remains of a star that had enough mass to go even farther
than that.  No force in the universe was able to stop it from contracting, so it
kept contracting until its mass occupied no volume ... zero.  It became even
more weird, and is composed of a substance that we don't know anything about
and can't describe, and occupies zero volume.

Contrary to popular fairy tales, a black hole doesn't reach out and "suck things in".
It's just so small (zero) that things can get very close to it.  You know that gravity
gets stronger as you get closer to an object, so if the object has no size at all, you
can get really really close to it, and THAT's where the gravity gets really strong.
You may weigh, let's say, 100 pounds on the Earth.  But you're like 4,000 miles
from the center of the Earth.  What if all of the earth's mass was crammed into
the size of a bean.  Then you could get 1 inch from it, and at that distance from
the mass of the Earth, you would weigh 25,344,000,000 pounds.
But Earth's mass is not enough to make a black hole.  That takes a minimum
of about 3 times the mass of the sun, which is right about 1 million times the
Earth's mass.   THEN you can get a lightweight black hole.
Do you see how it works now ?

I know.  It all seems too fantastic to be true.
It sure does.

8 0
3 years ago
What would happen to the railway lines in hot weather if there are no gaps in the track?
Olin [163]
When it gets hot, rails expand.  The gaps in the track allow for it to expand straight, but if there were no gaps, it could expand in unexpected directions, so it could be very dangerous for a train to go over it because they could be bent.

3 0
3 years ago
