Anit [1.1K]
4 years ago
6

Design a I O-to-4 encoder with inputs in the l-out-of-10 code and outputs in a code like normal BCD except that input lines 8 an

d 9 are encoded into "E" and "F'', respectively.

Engineering
1 answer:
egoroff_w [7]4 years ago
8 0

Answer and Explanation:

The answer is attached below

You might be interested in
ASAP PLEASEEEE HELP : Eccentricity, Inclination, True anomaly, Argument of perigee, Right ascension or the ascending node, Semi-
natita [175]

Answer:

d

Explanation:

Eternity because it could be culprited by the True Anomaly and the Argument of perigee

6 0
3 years ago
What is a combination circuit? A combination circuit:
Anon25 [30]

Answer:

Combination circuit; The basic strategy for the analysis of combination circuits involves using the meaning of equivalent resistance for parallel branches to transform the combination circuit into a series circuit.

Example:

The use of both series and parallel connections within the same circuit. In this case, light bulbs A and B are connected by parallel connections and light bulbs C and D are connected by series connections. This is an example of a combination circuit.

7 0
3 years ago
A permanent magnet DC motor has an armature resistance of 0.5 Ω and when a voltage of 120 V is applied to the motor it reaches a
BaLLatris [955]

Answer:

12 N-m

Explanation:

The dc motor is operating at 24 V that is its terminal voltage V =24 V

Armature resistance  = 0.2 ohm

No load speed = 240 radian /sec

For motor we know that  as the motor is on no load so  so

Power developed in the motor

Now we know that power = torque× angular speed

So

3 0
4 years ago
If the atomic radius of copper is 0.128 nm, calculate the volume of its unit cell in cubic meters.
Alex_Xolod [135]

Answer:

Volume of face centered cubic cell=4.74531*10^{-29} m^3

Explanation:

Consider the face centered cubic cell:

1 atom at each corner of cube.

1 atom at center of each face.

Consider the one face (ABCD) as shown in attachment for calculation:

Length of the all sides of face centered cubic cell is L.

Volume of face centered cubic cell= L^3

Now Consider the figure shown in attachment:

According to Pythagoras theorem on ΔADC.

L^{2}+L^2=(4a)^2     (a is the atomic radius)

L=\frac{4a}{\sqrt{2}} (Put in the formula of Volume)

Volume of face centered cubic cell= L^3

Volume of face centered cubic cell= (\frac{4a}{\sqrt{2}})^3

Volume of face centered cubic cell= (\frac{4(0.128*10^{-9}}{\sqrt{2}})^3

Volume of face centered cubic cell=4.74531*10^{-29} m^3

3 0
4 years ago
g Write a program that takes in a positive integer as input, and outputs a string of 1's and 0's representing the integer in bin
Phoenix [80]

Answer:

The solution is written in Python

  1. binary = ""
  2. decimal = 13
  3. quotient = int(decimal / 2)
  4. remainder = decimal % 2
  5. binary = str(remainder) + binary
  6. while(quotient >0):
  7.    decimal = int(decimal / 2)
  8.    quotient = int(decimal / 2)
  9.    remainder = decimal % 2
  10.    binary = str(remainder) + binary
  11. print(binary)

Explanation:

Firstly, we declare a variable <em>binary</em> and initialize it with an empty string (Line 1). This <em>binary </em>is to hold the binary string.

Next, we declare variable <em>decimal, quotient </em>and<em> remainder </em>(Line 2-4). We assign a test value 13 to decimal variable and then get the first quotient by dividing decimal with 2 (Line 3). Then we get the remainder by using modulus operator, % (Line 4). The first remainder will be the first digit joined with the binary string (Line 5).

We need to repeat the process from Line 3-5 to get the following binary digits. Therefore create a while loop (Line 7) and set a condition that if quotient is bigger than 0 we keep dividing decimal by 2 and calculate the quotient and remainder and use the remainder as a binary digit and join it with binary string from the front (Line 9-11).

At last, we print the binary to terminal (Line 13).

4 0
4 years ago
