What is the smallest radius of an unbanked (flat) track around which a bicyclist can travel if her speed is 32 km/h and the coef
ficient of static friction between tires and track is 0.27?
2 answers:
You might be interested in
Answer:
- E = 11.55J
- Q = 0.17C
- E' = (1/4)E
Explanation:
- To calculate the amount of energy stored in the capacitor, you use the following formula:
C: capacitance = 3800.0*10^-6F
V: potential difference = 78.0V
The energy stored in the capacitor is 11.55J
- If the electrical energy stored in the capacitor is 6.84J, the charge on the capacitor is:
The charge on the capacitor is 0.17C
- If you take the capacitor as a parallel plate capacitor, you have that the energy stored on the capacitor is:
A: area of the plates
d: distance between plates
If the distance between plates is increased by a factor of 4, you have:
Then, the stored energy in the capacitor is decreased by a a factor of (1/4)
Answer:
Explanation:
Magnetic field creates a force perpendicular to a moving charge in its field which is equal to Bev where B is magnetic field , e is amount of charge on the moving charge and v is the velocity of charge particle .
This force provides centripetal force for creation of circular motion. If r be the radius of the circular path
Bev = mv² / r
r = mv / Be
2 ) If an electron is accelerated by an electric field created by potential difference V then electric field
= V / d where d is distance between two points having potential difference v .
force on charged particle
electric field x charge
= V /d x e
work done by field
= force x distance
= V /d x e x d
V e
This is equal to kinetic energy created
V e = 1/2 mv²
= 1/2 m (r²B²e² / m² )
V = r²B²e/ 2 m
e / m = 2 V/ r²B²
3 )
B =
In Helmholtz coils , distance between coil is equal to R so Z = R/2
B =
For N turns of coil and total field due to two coils
B =
=
= 9.0 x 10^-7 NI/R
