Someone please help me

A current of 4.00 mA flows through a copper wire. The wire has an initial diameter of 4.00 mm which gradually tapers to a diamet

lesya692 [45]

The change in mean drift velocity for electrons as they pass from one end of the wire to the other is 3.506 x 10⁻⁷ m/s and average acceleration of the electrons is 4.38 x 10⁻¹⁵ m/s².

The given parameters;

Current flowing in the wire, I = 4.00 mA
Initial diameter of the wire, d₁ = 4 mm = 0.004 m
Final diameter of the wire, d₂ = 1 mm = 0.001 m
Length of wire, L = 2.00 m
Density of electron in the copper, n = 8.5 x 10²⁸ /m³

The initial area of the copper wire;

$A_1 = \frac{\pi d^2}{4} = \frac{\pi \times (0.004)^2}{4} =1.257\times 10^{-5} \ m^2$

The final area of the copper wire;

$A_2 = \frac{\pi d^2}{4} = \frac{\pi (0.001)^2}{4} = 7.86\times 10^{-7} \ m^2$

The initial drift velocity of the electrons is calculated as;

$v_d_1 = \frac{I}{nqA_1} \\\\v_d_1 = \frac{4\times 10^{-3} }{8.5\times 10^{28} \times 1.6\times 10^{-19} \times 1.257\times 10^{-5}} \\\\v_d_1 = 2.34 \times 10^{-8} \ m/s$

The final drift velocity of the electrons is calculated as;

$v_d_2 = \frac{I}{nqA_2} \\\\v_d_2 = \frac{4\times 10^{-3} }{8.5\times 10^{28} \times 1.6\times 10^{-19} \times 7.86\times 10^{-7}} \\\\v_d_2 = 3.74\times 10^{-7} \ m/s$

The change in the mean drift velocity is calculated as;

$\Delta v = v_d_2 -v_d_1\\\\\Delta v = 3.74\times 10^{-7} \ m/s \ -\ 2.34 \times 10^{-8} \ m/s = 3.506\times 10^{-7} \ m/s$

The time of motion of electrons for the initial wire diameter is calculated as;

$t_1 = \frac{L}{v_d_1} \\\\t_1 = \frac{2}{2.34\times 10^{-8}} \\\\t_1 = 8.547\times 10^{7} \ s$

The time of motion of electrons for the final wire diameter is calculated as;

$t_2 = \frac{L}{v_d_1} \\\\t_2= \frac{2}{3.74 \times 10^{-7}} \\\\t_2 = 5.348 \times 10^{6} \ s$

The average acceleration of the electrons is calculated as;

$a = \frac{\Delta v}{\Delta t} \\\\a = \frac{3.506 \times 10^{-7} }{(8.547\times 10^7)- (5.348\times 10^6)} \\\\a = 4.38\times 10^{-15} \ m/s^2$

Thus, the change in mean drift velocity for electrons as they pass from one end of the wire to the other is 3.506 x 10⁻⁷ m/s and average acceleration of the electrons is 4.38 x 10⁻¹⁵ m/s².

Learn more here: brainly.com/question/22406248

7 0

3 years ago

The Solar System is made up of eight planets, numerous comets, asteroids, and moons, and the Sun. The force that holds all of th

Nastasia [14]

Answer:

B. GRAVITY is the answer

7 0

3 years ago

Read 2 more answers

A golfer is on the edge of a 12.5 m bluff overlooking the 18th hole which is located 60 m from the base of the bluff. She launch

Lina20 [59]
