How do you solve the resultant force and direction.

Physics

1 answer:

Schach [20]3 years ago

7 0

Answer:

<h2>To find the resultant force <u>subtract the magnitude of the smaller force from the magnitude of the larger force.</u> The direction of the resultant force is in the same direction as the larger force. A force of 5 N acts to the right, and a force of 3 N act to the left. Calculate the resultant force.</h2>

You might be interested in

What is the force and distance relationship for a fixed pulley?

leva [86]

Answer:

Force is a vector quantity which when applied to an object can cause change in its velocity. When Force is applied to an object, the object if stationary moves to a certain distance depending upon the amount of force applied.

A pulley is a wheel with a groove that holds a rope, cable or belt, and is used to help lift an object.

The relationship of Force and Distance is the same for a fixed pulley as well. Except for one thing:

Normally the distance covered by an object is in the direction of the Force.

Using a pulley, an object can be moved with that same Force in a different direction. Using a pulley, a person can apply force in a direction suitable for him while moving the object.

<em> Force = mass of an object * Distance Covered</em>

6 0

3 years ago

A spring-loaded toy gun is used to shoot a ball straight up inthe air. The ball reaches a maximum height H, measuredfrom the equ

rewona [7]

Answer:

H' = H/4

Explanation:

By applying the law of conservation of energy to this problem, we know that:

Elastic Potential Energy Stored by Spring = Gravitational Potential Energy of ball

(1/2)kx² = mgH

H = (1/2)kx²/mg -------------- equation (1)

where,

H = Height reached by the ball

x = compression of spring

k = stiffness of spring

m = mass of ball

g = acceleration due to gravity

Now, if we make the compression to half of its value:

x' = x/2

then:

H' = (1/2)k(x/2)²/mg

H' = (1/4)(1/2)kx²/mg

using equation (1), we get:

6 0

3 years ago

What is force??????<br> ⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀

8090 [49]

Answer:

Force is an external agency that change or tends to change the position of a body

6 0

3 years ago

A source emits sound with a frequency of 860 Hz. It is moving at 20.0 m/s toward a stationary reflecting wall. If the speed of s

Galina-37 [17]

Answer:

$f_o=860\ Hz$

Explanation:

Given:

original frequency of sound wave, $f=860\ Hz$

speed of the sound source, $v_s=20\ m.s^{-1}$

original speed of sound wave from the source, $s=343\ m.s^{-1}$

<u>According to the Doppler's effect:</u>

$\frac{f_s}{f_o} =\frac{s+v_s}{s-v_o}$

The sound is reflected from the wall and the source is moving towards the wall and observer is also riding the same source.

The velocity of the observer, $v_o=-20\ m.s^{-1}$

$\frac{860}{f_o} =\frac{s+20}{s-(-20)}$

$f_o=860\ Hz$

3 0

3 years ago

Read 2 more answers

A ball of mass m= 450.0 g traveling at a speed of 8.00 m/s impacts a vertical wall at an angle of θi =45.00 below the horizontal

Mkey [24]

Answer:

F = 20.4 i ^

Explanation:

This exercise can be solved using the ratio of momentum and amount of movement.

I = F t = Dp

Since force and amount of movement are vector quantities, each axis must be worked separately.

X axis

Let's look for speed

cos 45 = vₓ / v

vₓ = v cos 45

vₓ = 8 cos 45

vₓ = 5,657 m / s

We write the moment

Before the crash p₀ = m vₓ

After the shock $p_{f}$ = -m vₓ

The variation of the moment Δp = mvₓ - (-mvₓ) = 2 m vₓ

The impulse on the x axis Fₓ t = Δp

Fₓ = 2 m vₓ / t

Fx = 2 0.450 5.657 / 0.250

Fx = 20.4 N

We perform the same calculation on the y axis

sin 45 = vy / v

vy = v sin 45

vy = 8 sin 45

vy = 5,657 m / s

We calculate the initial momentum po = m $v_{y}$

Final moment $p_{f}$ = m $v_{y}$

Variations moment Δp = m $v_{y}$ - m $v_{y}$ = 0

Force in the Y-axis $F_{y}$ = 0

Therefore the total force is

F = fx i ^ + Fyj ^

F = Fx i ^

F = 20.4 i ^

3 0

4 years ago
