Please i want to paraphrase this paragraph please helppppppppp don't skip!!!!!!

1 answer:

expeople1 [14]3 years ago

4 0

I’m sorry but I can’t read all of it maybe you should write it in type so we can read it.

You might be interested in

When you first start a car after it has been sitting for more than an hour, it pollutes up to ......times more than when the eng

lesya [120]

20 time more then when it’s warm

6 0

4 years ago

Read 2 more answers

What's the function of the rubber, square-cut seal positioned around the caliper piston?

lozanna [386]

Explanation:

The square cut seal is what allows the caliper piston to retract back into its housing. Just because you can manually push the piston in, doesn't mean the square cut seal is working. Rapid brake pad wear, brake drag or brake pull are key indicators that the square cut seal is comprised

5 0

3 years ago

A design team is working on creating a new energy-efficient light. They have completed the following steps:

Anastaziya [24]

I believe that it is to produce a product

7 0

3 years ago

Read 2 more answers

Air, at a free-stream temperature of 27.0°C and a pressure of 1.00 atm, flows over the top surface of a flat plate in parallel f

Morgarella [4.7K]

Answer:

Explanation:

Given that:

V = 12.5m/s

L= 2.70m

b= 0.65m

$T_{ \infty} = 27^0C= 273+27 = 300K$

$T_s= 127^0C = (127+273)= 400K$

P = 1atm

Film temperature

$T_f = \frac{T_s + T_{\infty}}{2} \\\\=\frac{400+300}{2} \\\\=350K$

dynamic viscosity =

$\mu =20.9096\times 10^{-6} m^2/sec$

density = 0.9946kg/m³

Pr = 0.708564

K= 229.7984 * 10⁻³w/mk

Reynolds number,

$Re = \frac{SUD}{\mu} =\frac{\ SUl}{\mu}$

$=\frac{0.9946 \times 12.5\times 2.7}{20.9096\times 10^-^6} \\\\Re=1605375.043$

we have,

$Nu=\frac{hL}{k} =0.037Re^{4/5}Pr^{1/3}\\\\\frac{h\times2.7}{29.79\times 10^-63} =0.037(1605375.043)^{4/5}(0.7085)^{1/3}\\\\h=33.53w/m^2k$

we have,

heat transfer rate from top plate

$\theta _1 =hA(T_s-T_{\infty})\\\\A=Lb\\\\=2.7*0.655\\\\ \theta_1=33.53*2.7*0.65(127/27)\\\\ \theta_1=5884.51w$

7 0

3 years ago

A body is moving with simple harmonic motion. It's velocity is recorded as being 3.5m/s when it is at 150mm from the mid-positio

natima [27]

Answer:

1) A=282.6 mm

2) $a_{max}=60.35\ m/s^2$

3)T=0.42 sec

4)f= 2.24 Hz

Explanation:

Given that

V=3.5 m/s at x=150 mm ------------1

V=2.5 m/s at x=225 mm ------------2

Where x measured from mid position.

We know that velocity in simple harmonic given as

$V=\omega \sqrt{A^2-x^2}$

Where A is the amplitude and ω is the natural frequency of simple harmonic motion.

From equation 1 and 2

$3.5=\omega \sqrt{A^2-0.15^2}$ ------3

$2.5=\omega \sqrt{A^2-0.225^2}$ --------4

Now by dividing equation 3 by 4

$\dfrac{3.5}{2.5}=\dfrac {\sqrt{A^2-0.15^2}}{\sqrt{A^2-0.225^2}}$

$1.96=\dfrac {{A^2-0.15^2}}{{A^2-0.225^2}}$

So A=0.2826 m

A=282.6 mm

Now by putting the values of A in the equation 3

$3.5=\omega \sqrt{A^2-0.15^2}$

$3.5=\omega \sqrt{0.2826^2-0.15^2}$

ω=14.609 rad/s

Frequency

ω= 2πf

14.609= 2 x π x f

f= 2.24 Hz

Maximum acceleration

$a_{max}=\omega ^2A$

$a_{max}=14.61 ^2\times 0.2826\ m/s^2$

$a_{max}=60.35\ m/s^2$

Time period T

$T=\dfrac{2\pi}{\omega}$

$T=\dfrac{2\pi}{14.609}$

T=0.42 sec

8 0

4 years ago
