Answer:
All the detailed steps are mentioned in pictures.
Explanation:
See attached pictures.
Answer:
Explanation:
Brake systems are most likely to fail at the ends. One of the most common problems is a trailer lighting splitter is left on. With time and usage, the fuse can blow interrupting the signal path from the switch to the bulb.
Answered by the <u><em>ONE </em></u>& <u><em>ONLY</em></u> <u><em>#QUEEN aka #DRIPPQUEENMO</em></u>
<u><em>HOPE THIS HELPED!!!</em></u>
Answer:
THANKS FOR THE POINTS!!!!!!!
Hx115 it's pretty fine looking
Answer:
Tmax= 46.0 lb-in
Explanation:
Given:
- The diameter of the steel rod BC d1 = 0.25 in
- The diameter of the copper rod AB and CD d2 = 1 in
- Allowable shear stress of steel τ_s = 15ksi
- Allowable shear stress of copper τ_c = 12ksi
Find:
Find the torque T_max
Solution:
- The relation of allowable shear stress is given by:
τ = 16*T / pi*d^3
T = τ*pi*d^3 / 16
- Design Torque T for Copper rod:
T_c = τ_c*pi*d_c^3 / 16
T_c = 12*1000*pi*1^3 / 16
T_c = 2356.2 lb.in
- Design Torque T for Steel rod:
T_s = τ_s*pi*d_s^3 / 16
T_s = 15*1000*pi*0.25^3 / 16
T_s = 46.02 lb.in
- The design torque must conform to the allowable shear stress for both copper and steel. The maximum allowable would be:
T = min ( 2356.2 , 46.02 )
T = 46.02 lb-in
