Answer:
a) 358.8 KJ/kg
b) 0.0977 KJ/K- kg
c) 83.28%
Explanation:
N2 at 300 k. ( use the properties of N2 at 300 k (T1) )
Cp = 1.04 KJ/kg-k , Cv = 0.743 KJ/Kgk , R = 0.1297 KJ/kgk , y = 1.4 ,
Given data:
T2 = 645 k
P1 = 1 bar , P2 = 10.5 bar
<u>a)Determine the work input in KJ/Kg of N2 flowing </u>
Winput = h2 - h1 = Cp( T2 - T1 ) = 1.04 ( 645 - 300 ) = 358.8 KJ/kg
<u>b) Determine the rate of entropy in KJ/K- kg of N2 flowing </u>
Rate of entropy ( Δs ) = Cp*InT2/T1 - R*In P2/P1
= 1.04 * In (645/300) - 0.1297 * In ( 10.5 / 1 )
= 0.0977 KJ/K- kg
<u>c) Determine isentropic compressor efficiency </u>
Isentropic compressor efficiency = 83.28%
calculated using the relation below
( h'2 - h1 ) / ( h2 - h1 ) = ( T'2 - T1 ) / ( T2 - T1 )
where T'2 = 587.314
Answer:
(a)Volume in liters=5.3 liters.
(b)Volume in liters/minute=31.8 liters/minute.
Explanation:
Given:
Diameter of cylinder ,D=150 mm
Stroke,L=300 mm
Time ,t=10 sec
we know that swept volume of cylinder
So
(a) Volume in liters =5.3 liters ( 1=1000 liters)
(b) When we divide swept volume by time(in minute) we will get liters/minute.
We know that 1 minute=60 sec
⇒10 sec= minute
So volume displace in liters/minute=31.8 liters/minute.
Answer:
Option A is correct
Explanation:
As we know
Inductive Susceptance = ½(pi)*f*L
Or Inductive Susceptance is inversely proportional to the frequency
Likewise conductive Susceptance = 2 (pi)*f*C
Conductive Susceptance is directly proportional to the frequency
When the frequency will reach the value zero, then the Inductive Susceptance will become infinite
Hence, inductor will dominate in determining the equivalent impedance of this parallel combination
Option A
Answer:
Production Function : TFSq = f { ingredient 1 ...... ing. i }
Increasing/ Constant/ Increasing Returns to Scale :
Output change > / = / < Input change respectively
Explanation:
Production Function is the relationship between production inputs & outputs, given technology. It denotes the maximum output that can be generated with given inputs.
Tutti Frutti Smoothie [TFS] quantity = Function of {Ingredient1.....ingredient i}
Returns to Scale represents change in output when all inputs change in same proportion.
- Constant Returns to Scale [CRS] : Output Change = All inputs change
- Increasing Returns to Scale [IRS] : Output Change > All inputs change
- Negative Returns to Scale [NRS] : Output Change < All inputs change
When all inputs (ingredients) change by same proportion i.e get twice 2X :- If output of Tutti Frutti Smoothie increases by > 2X i.e 3X - IRS. If it increases equal ie 2X - CRS. If it increases lesser i.e 1.5X - CRS.
