Ierofanga [76]
4 years ago
14

Draw the net force arrow on the picture to the left 14 points!

Physics
1 answer:
AveGali [126]4 years ago
7 0

Answer: use use a ruler and measure, then add to the arrows

Explanation:

You might be interested in
The maximum range of projectle is R° if projected at angle of 45°. It'll be 300% of Range of projectile if projected at angle? a
geniusboy [140]

Answer:

The maximum range is 300% of the range of the projectile is projected at an angle of 9.74°.

None of the options are correct.

Explanation:

Normally, ignoring air resistance, for projectile motion, the range (horizontal distance travelled) of the motion is given as

R = (u² sin 2θ)/g

where

u = initial velocity of the projectile

θ = angle above the horizontal at which the projectile was launched

g = acceleration due to gravity = 9.8 m/s²

The range is maximum when θ = 45°

R when θ = 45° is

R = (u² sin 90°)/g = (u²/g)

We are then told that this maximum range is 300% of the value obtainable for the range at a particular angle

Maximum range = 3R

(u²/g) = 3(u² sin 2θ)/g

Sin 2θ = (1/3)

2θ = sin⁻¹ (1/3) = 19.47°

θ = (19.47°/2) = 9.74°

Hope this Helps!!!

4 0
3 years ago
Onur drops a basketball from a height of 10\,\text{m}10m10, start text, m, end text on Mars, where the acceleration due to gravi
Doss [256]

Answer:

Explanation:

Given that,

Basket ball is drop from height

H=10m

It is dropped on planet mass

And the acceleration due to gravity on Mars is given as

g= 3.7m/s²

Time taken for the ball to reach the ground

Initial velocity of the body is zero

u=0m/s

Using equation of motion: free fall

H = ut + ½gt²

10 = 0•t + ½ × 3.7 ×t²

10 = 0 + 1.85t²

10 = 1.85t²

Then, t² =10/1.85

t² = 5.405

t = √ 5.405

t = 2.325seconds

So the time the ball spend on the air before reaching the ground is 2.325 seconds

5 0
3 years ago
Follow these steps to solve this problem: Two identical loudspeakers, speaker 1 and speaker 2, are 2.0 m apart and are emitting
horsena [70]

Answer:

Explanation:

Wave length of sound from each of the  speakers = 340 / 1700 = .2 m = 20 cm

Distance between first speaker and the given point = 4 m.

Distance between second speaker and the given sound

= √ 4² + 2² = √16 +4 = √20 = 4.472 m

Path difference = 4.472 - 4 = .4722 m.

Path difference / wave length = 0.4772 / 0.2 = 2.386

This is a fractional integer which is neither an odd nor an  even multiple of half wavelength. Hence this point of neither a perfect constructive nor a perfect destructive interference.

7 0
4 years ago
CHEGG 42 mT magnetic field points due west. If a proton of kinetic energy 9 x 10-12 J enters this field in an upward direction,
alexdok [17]

Answer:

The  magnitude of the Force is  F = 697 *10^{-15}N  and the direction is South

Explanation:

From the question we are told that

         The magnetic field point due west and since East point toward the positive x -axis(i)  then this magnetic field would be mathematically represented as

                \= B = 42(-i)mT = 42*10^{-3} (-i) T

Now from the question we are told that the kinetic energy is

             KE = 9*10^{-12}J

Now this kinetic energy can be mathematically represented as

                  KE = \frac{1}{2}mv^2

Where m is the mass of proton which has a general value of

           m = 1.67*10^{-27}kg

Now making the subject of the formula

                v = \sqrt{\frac{KE}{0.5 * m} }

Substituting values we have

               v = \sqrt{\frac{9*10^{-12}}{0.5 * 1.67*10^{-27}} }

                 = 10.37*10^7m/s

Now from the question we are told that proton is moving upward which is in the positive z direction so the velocity of the proton would be in the positive

So the velocity would be

            \= v = 10.37*10^{7} \r k \ m/s

Now the magnetic Force can be mathematically represented as

          \= F = q \= v * \=  B

Where q is the charge on the proton which has a general value of  q =1.6*10^{-19}C

Now substituting the value

          \= F = 1.6*10^{-19 } * (10.37 *10^7) \r k * (42 *10^{-3})(-i)

              = 697*10^{-15} J

Now according to Fleming's left hand rule the direction of the magnetic force is south toward the negative Y - direction (-j)

So the force can be denoted as

                 \= F = 697*10^{-15}(-j) N





6 0
3 years ago
Pun zapato de golf tiene 10 tacos cada uno con un área de 0.01 pulgadas en contacto con el piso suponga que caminar hay un insta
Mars2501 [29]

Answer:

Las presión ejercida por los tacos sobre el suelo es 900 libras por pulgada cuadrada.

Explanation:

Según la Física, comprendemos que la presión es igual a la fuerza dividida por área. En este caso, el peso de la persona dividida por área total de los tacos de los zapatos de golf suponiendo una distribución uniforme de la fuerza. Es decir:

\sigma = \frac{W}{n\cdot A_{T}} (Eq. 1)

Donde:

\sigma - Presión, medida en libras por pulgada cuadrada.

W - Peso de la persona, medida en libras.

n - Cantidad de tacos en los zapatos, adimensional.

A_{T} - Área del taco, medida en pulgadas cuadradas.

Si conocemos que W = 180\,lb, n = 20 y A_{T} = 0.01\,in^{2}, la presión es:

\sigma = \frac{180\,lb}{(20)\cdot (0.01\,in^{2})}

\sigma = 900\,psi

Las presión ejercida por los tacos sobre el suelo es 900 libras por pulgada cuadrada.

3 0
3 years ago
