PLEASEE HELP ME....

Which of the following is characteristic of the second stage within a demographic transition?

Elan Coil [88]

The answer is A) <span>The death rate begins to fall, but birth rates remain high for a time.</span>

3 0

4 years ago

A metal has a strength of 414 MPa at its elastic limit and the strain at that point is 0.002. Assume the test specimen is 12.8-m

ser-zykov [4K]

To solve this problem, we will start by defining each of the variables given and proceed to find the modulus of elasticity of the object. We will calculate the deformation per unit of elastic volume and finally we will calculate the net energy of the system. Let's start defining the variables

Yield Strength of the metal specimen

$S_{el} = 414Mpa$

Yield Strain of the Specimen

$\epsilon_{el} = 0.002$

Diameter of the test-specimen

$d_0 = 12.8mm$

Gage length of the Specimen

$L_0 = 50mm$

Modulus of elasticity

$E = \frac{S_{el}}{\epsilon_{el}}$

$E = \frac{414Mpa}{0.002}$

$E = 207Gpa$

Strain energy per unit volume at the elastic limit is

$U'_{el} = \frac{1}{2} S_{el} \cdot \epsilon_{el}$

$U'_{el} = \frac{1}{2} (414)(0.002)$

$U'_{el} = 414kN\cdot m/m^3$

Considering that the net strain energy of the sample is

$U_{el} = U_{el}' \cdot (\text{Volume of sample})$

$U_{el} = U_{el}'(\frac{\pi d_0^2}{4})(L_0)$

$U_{el} = (414)(\frac{\pi*0.0128^2}{4}) (50*10^{-3})$

$U_{el} = 2.663N\cdot m$

Therefore the net strain energy of the sample is $2.663N\codt m$

6 0

3 years ago

20 POINTS!!!

hram777 [196]

I think its inductance. If its not then I think its none of the above

5 0

3 years ago

A cylindrically shaped piece of collagen (a substance found in the body in connective tissue) is being stretched by a force that

Marat540 [252]

Answer:

Part(a): The value of the spring constant is $3.11 \times 10^{2}~Kg~s^{-2}$ .

Part(b): The work done by the variable force that stretches the collagen is $1.5 \times 10^{-6}~J$ .

Explanation:

Part(a):

If ' $k$ ' be the force constant and if due the application of a force ' $F$ ' on the collagen ' $\Delta l$ ' be it's increase in length, then from Hook's law

$F = k~\Delta l....................................................................(I)$

Also, Young's modulus of a material is given by

$Y = \dfrac{F/A}{\Delta l/l}...............................................................(II)$

where ' $A$ ' is the area of the material and ' $l$ ' is the length.

Comparing equation ( $I$ ) and ( $II$ ) we can write

$&& Y = \dfrac{l~k}{A}\\&or,& k = \dfrac{Y~A}{l}\\&or,& k = \dfrac{Y~(\pi~r^{2})}{l}$

Here, we have to consider only the circular surface of the collagen as force is applied only perpendicular to this surface.

Substituting the given values in equation ( $III$ ), we have

$k = \dfrac{3.10 \times 10^{6}~N~m^{-2} \times \pi \times (0.00093)^{2}~m^{2}}{.027~m} = 3.11 \times 10^{2}~Kg~s^{-2}$

Part(b):

We know the amount of work done ( $W$ ) on the collagen is stored as a potential energy ( $U$ ) within it. Now, the amount of work done by the variable force that stretches the collagen can be written as
