Question

A spur gearset has a module of 6 mm and a velocity ratio of 4. The pinion has 16 teeth. Find the number of teeth on the driven gear, the pitch diameters, and the theoretical center-to-center distance

Answer 1

Answer:

NG=64 teeth

dG=384mm

dP=96mm

C=240mm

Explanation:

step one:

given data

module m=6mm

velocity ratio VR=4

number of teeth of pinion Np=16

Step two:

Required

1. Number of teeth on the driven gear

$N_G=N_P*V_R\\\\N_G=16*4\\\\N_G=64$

The driven gear has 64 teeth

2.  The pitch diameters

The driven gear diameter

$d_G=N_G*m\\\\d_G=64*6\\\\d_G=384$

The driven gear diameter is 384mm

The pinion diameter

$d_P=N_P*m\\\\d_P=16*6\\\\d_P=96$

Pinion diameter is 96mm

3. Theoretical center-to-center distance

$C=\frac{d_G+d_P}{2} \\\\C=\frac{384+96}{2} \\\\C=\frac{480}{2}\\\\C=240$

The theoretical center-to-center distance is 240mm
