Hii! help asap. i’ll give brainliest thanks!
1 answer:
You might be interested in
Answer:
Yes, it will produce a diffraction pattern.
a. 3.9 mm b. 1.95 mm
Explanation:
The light shined from a single slit will produce a diffraction pattern because, the wavefront act as wavelets which generates its own wave according to Huygens principle. This therefore causes the diffraction pattern.
Given
wavelength of green light, λ = 520 nm = 520 × 10⁻⁹ m = 5.20 × 10⁻⁷ m
width of slit, d = 0.440 mm = 0.44 × 10⁻³ m = 4.4 × 10⁻⁴ m
Distance of slit from central maximum , D = 1.65 m
Distance of first minimum from central maximum, y = ?
a. The relationship between the slit width and wavelength is given by [tex} dsinθ = mλ [/tex]where d = slit width, θ = angular distance from central maximum, λ = wavelength of light and m = ±1, ±2, ±3...
The relationship between y and D is given by
Since θ is small, sinθ ≈ θ ≈ tanθ
so, dθ = mλ ⇒ θ = mλ/d = y/D
Therefore, y = mλD/d
Now, for the first minimum above the slit, m = +1 and for the first minimum below the slit, m = -1. So, y₁ = λD/d and y₋₁ = -λD/d. So, the width of the central maximum Δy is the difference between the first minima below and above the central maximum. So, Δy = y₁ - y₋₁ = λD/d -(-λD/d) = 2λD/d
Substituting the values from above, Δy= 2 × 5.20 × 10⁻⁷ × 1.65/4.4 × 10⁻⁴ = 3900 × 10⁻⁶ m = 3.9 × 10⁻³ m = 3.9 mm
b. The first order fringe is the fringe located between the first minimum and the second minimum. From dsinθ = mλ and tanθ = y/D when θ is small, sinθ ≈ θ ≈ tanθ. So, y = mλD/d. Let m= 1 and m=2 be the first and second minima respectively. So,y₁ = λD/d and y₂ = 2λD/d. The difference Δy₁ = y₂ - y₁ is the width of the first order fringe. Therefore, Δy₁ = 2λD/d - λD/d= λD/d. Substituting the values from above, we have
λD/d= 5.20 × 10⁻⁷ × 1.65/4.4 × 10⁻⁴= 1.95 × 10⁻³ m = 1.95 mm
The graph represents an object moving at constant velocity
Explanation:
A graph of velocity (v) versus time (t) of an object is generally used to give information about the motion of an object. In fact, from this graph, it is possible to infer several pieces of information:
- The slope of the graph corresponds to the acceleration of the object. In fact, the acceleration of an object is defined as the rate of change of the velocity:
, which also corresponds to the slope of the graph
- The area under the curve between two times
corresponds to the distance travelled by the object in that time interval.
In this problem, we have an object whose velocity-time graph corresponds to a horizontal line. We said that the slope of the graph corresponds to the acceleration of the object: since the slope of an horizontal line is zero, this means that the acceleration of this object is zero, and therefore the object is travelling at constant velocity.
Learn more about velocity:
#LearnwithBrainly
