MrMuchimi
3 years ago
6

There is currently an effort in the United States to replace incandescent light bulbs with more energy-efficient technologies, i

ncluding compact fluorescent lights (CFLs) and light-emitting diodes (LEDs). The lumen [lm] is the SI unit of luminous flux, a measure of the perceived power of light. Luminous flux is adjusted to reflect the varying sensitivity of the human eye to different wavelengths of light. To test the power usage, you run an experiment and measure the following data. Create a proper plot of these data, with electrical consumption (EC) on the ordinate.
Luminous Flux (LF) [11m] Incandescent CFL LED
80 16 1.7
200 5 3
400 38 10 6
600 55 9
750 68 18 12
1250 27
1400 105 33

On the graph, use solid blue circles for incandescent bulbs, solid red squares for CLFs, and open black diamonds for LEDs.
Engineering
1 answer:
jenyasd209 [6]3 years ago
5 0
Can you help me by solving this question

You might be interested in
Which explanation best identifies why the company in the following scenario has decided against investing in solar energy?
pickupchik [31]

Answer:

The company found the cost of the required photovoltaic cells too expensive.

Explanation:

Solar energy can be used as an alternative source of supply for fuel. Solar energy is a renewable source of energy, that is it keeps on replenishing every day. Also solar energy does not require a lot of maintenance.

The cost required is starting a solar system is very high because one needs to buy solar panel, photovoltaic cells for batteries, inverters and so on.

From the question, the company decided against solar energy for the time being. This means that probably in the future they might consider it. Therefore it is as a result of the economic situation of the company that they have not set up a solar system because the cost of the required photovoltaic cells too expensive.

8 0
3 years ago
Neon is compressed from 100 kPa and 20◦C to 500 kPa in an isothermal compressor. Determine the change in the specific volume and
PIT_PIT [208]

Answer:

The specific volume is reduced in 80 per cent due to isothermal compression.

Specific enthalpy remains constant.

Explanation:

Let suppose that neon behaves ideally, the equation of state for ideal gases is:

P\cdot V = n\cdot R_{u}\cdot T

Where:

P - Pressure, measured in kilopascals.

V - Volume, measured in cubic meters.

n - Molar quantity, measured in kilomoles,

T - Temperature, measured in kelvins.

R_{u} - Ideal gas constant, measured in \frac{kPa\cdot m^{3}}{kmol\cdot K}.

On the other hand, the molar quantity (n) and specific volume (\nu), measured in cubic meter per kilogram, are defined as:

n = \frac{m}{M} and \nu = \frac{V}{m}

Where:

m - Mass of neon, measured in kilograms.

M - Molar mass of neon, measured in kilograms per kilomoles.

After replacing in the equation of state, the resulting expression is therefore simplified in term of specific volume:

P\cdot V = \frac{m}{M}\cdot R_{u}\cdot T

P\cdot \nu = \frac{R_{u}\cdot T}{M}

Since the neon is compressed isothermally, the following relation is constructed herein:

P_{1}\cdot \nu_{1} = P_{2}\cdot \nu_{2}

Where:

P_{1}, P_{2} - Initial and final pressure, measured in kilopascals.

\nu_{1}, \nu_{2} - Initial and final specific volume, measured in cubic meters per kilogram.

The change in specific volume is given by the following expression:

\frac{\nu_{2}}{\nu_{1}} = \frac{P_{1}}{P_{2}}

Given that P_{1} = 100\,kPa and P_{2} = 500\,kPa, the change in specific volume is:

\frac{\nu_{2}}{\nu_{1}} = \frac{100\,kPa}{500\,kPa}

\frac{\nu_{2}}{\nu_{1}} = \frac{1}{5}

The specific volume is reduced in 80 per cent due to isothermal compression.

Under the ideal gas supposition, specific enthalpy is only function of temperature, as neon experiments an isothermal process, temperature remains constant and, hence, there is no change in specific enthalpy.

Specific enthalpy remains constant.

8 0
3 years ago
Source 1 can supply energy at the rate of 11000 kJ/min at 310°C. A second Source 2 can supply energy at the rate of 110000 kJ/mi
VladimirAG [237]

Answer:

Source 2.

Explanation:

The efficiency of the ideal reversible heat engine is given by the Carnot's power cycle:

\eta_{th} = 1 - \frac{T_{L}}{T_{H}}

Where:

T_{L} - Temperature of the cold reservoir, in K.

T_{H} - Temperature of the hot reservoir, in K.

The thermal efficiencies are, respectively:

Source 1

\eta_{th} = 1 - \frac{311.15\,K}{583.15\,K}

\eta_{th} = 0.466 \,(46.6\,\%)

Source 2

\eta_{th} = 1 - \frac{311.15\,K}{338.15\,K}

\eta_{th} = 0.0798 \,(7.98\,\%)

The power produced by each device is presented below:

Source 1

\dot W = (0.466)\cdot (11000\,\frac{kJ}{min})\cdot (\frac{1\,min}{60\,s} )

\dot W = 85.433\,kW

Source 2

\dot W = (0.0798)\cdot (110000\,\frac{kJ}{min})\cdot (\frac{1\,min}{60\,s} )

\dot W = 146.3\,kW

The source 2 produces the largest amount of power.

8 0
3 years ago
A clay sample has a wet mass of 417 g, a volume of 276 cm3, and a specific gravity of 2.70. When oven dried, the mass becomes 22
nataly862011 [7]

Answer:

a. WATER CONTENT.

mass of water (MW)= 417g - 225g

Mw= 192g

M= (Mw / Ms)

M= [192/417]

M= 0.46

M= 46.0%

b. Void Ration (e)

To calculate the void ratio we must first calculate the volume of solids. Then we can find the volume of voids by subtracting the volume of solids from the total volume.

Ps= (Ms/Vs)=GsPw

Therefore

Vs= (Ms/GsPw)

Vs= (417/ 2.70*1000)

Vs= 0.154cm3

But V= Vv+Vs

Vv=V-Vs

e= (Vv/Vs)

8 0
3 years ago
"How would you direct traffic in the result of a catastrophic earthquake?"
11Alexandr11 [23.1K]

Answer:

In the result of a earthquake, you should direct people into areas that are safe, such as places where the ground has not been broken up, and then tell people to get out of their cars and be careful. You should also have them carry any valuable items out of the car(if they have time), and then wait until the initial shocks and aftershocks are over, and then tell them to get back into their cars and then drive carefully and safely.

8 0
3 years ago
