a) The operation of a heat pump involves the extraction of energy in the form of heat Q₁ from a cold source
b) The modifications required to convert a plant operating on an ideal Carnot cycle to a plant operating on a Rankine cycle involves
i) Complete condensation of the vapor at the condenser to saturated liquid for pumping to the boiler
ii) Heating of the pumped, pressurized water to the boiler pressure
Explanation:
a) 1 - 2. Wet vapor enters compressor where it undergoes isentropic compression to state 2 by work W₁₂
2 - 3. The vapor enters the condenser at state 2 where it undergoes isobaric and isothermal condensation to a liquid with the evolution of heat Q₂
3 - 4. The condensed liquid is expanded isentropically with the work done equal to W₃₋₄
4 - 1. At the state 4, with reduced pressure from the previous expansion, the liquid makes its way to the evaporator where it absorbs heat, Q₁, from the body to be cooled.
b. i) Complete condensation of the vapor at the condenser to saturated liquid for pumping to the boiler
Here the condensation process is modified from partial condensation to complete condensation at the same temperature which reduces the size of the pump required to pump the liquid water as opposed to pumping steam plus liquid
ii) Heating of the pumped, pressurized water to the boiler pressure
The pumped water at state 4 will be required to be heated to saturated water temperature equivalent to the boiler pressure, hence heat will need to be added at state.
Sketches of the schematic of a Basic Rankine cycle is attached
Answer:
-10.83m
Explanation:
Please see the attachment
Answer:
See attachment for complete answer step by step solving
Explanation:
Given that:
The anchor shown is used to tie tower guy cables to the ground and is supported by a distributed force from the soil, which can be approximated as shown. The anchor also is subjected to the loads shown, where P1 = 5 kNand P2 = 3 kN . The anchor is made from aluminum with E = 69 GPa . It is a cylindrical rod with diameter d1 = 4 cm with three segments of length L = 2 m . One end of the rod is linearly tapered to a diameter of d2 = 2 cm.
a. Calculate the intensity of the reaction load, Po
b. Use the reaction found in Part A, po = 13 kN/m , and calculate the total change in length for the anchor.
