Answer:
W=-109.12 kJ/kg
Q=-76.34 kJ/kg
Explanation:
The needed work W we will calculate by using the work equation for polytropic process and the heat transfer Q we will calculate by using the energy balance equation.
Before the calculations we first need to determine the final temperature T2. We will do that by using the given initial temperature T1 = 10°C, the given initial p_1 = 120 kPa and final p_2 = 800 kPa pressure and the polytropic index n = 1.2. Before the calculation we need to express the temperature in K units.
T1 = 10°C + 273 K = 283 K
T2 = ((p_2/p_1)^(n-1)/n)* T1
T2 = 388 K
Now we can use the heat capacity C_v, = 0.3122 kJ /kg K and the temperatures T1 and T2 to determine the change in internal energy ΔU.
ΔU = C_v*(T2-T1)
ΔU = 32.78 kJ/kg
to determine the work we will also need the initial v1 and final v2 specific volume. The initial specific volume v1 we can determine from the ideal gas equation. For the calculation we will need the initial pressure p_1, temperature T1 and the specific gas constant R = 0.2081 kJ /kg K.
v1=R*T1/p_1
v1=0.4908 m^3/kg
For the final specific volume we need to replace the initial temperature and pressure with the final.
v2=R*T2/p_2
v2=0.1009 m^3/kg
The work W is then:
W=p_2*v2-p_1*v1/n-1
W=-109.12 kJ/kg
The heat transfer Q we can calculate form the energy balance equation. For the calculation we will need the calculated work W and the change in internal energy ΔU.
Q=W+ΔU
Q=-76.34 kJ/kg
Answer:
She is a aerospace engineer.
Explanation:
This is because she works is the aerospace industry, so she must be an aerospace engineer.
Answer:
★ The answers ARE B,A,D,D,A !
Explanation:
Hope you have a great day
Answer: True
Explanation: Machining is a procedure in which a material is given a desired shape by removing the excess with help of tool sharp enough to cut the material.It is a sort of primary manufacturing process which is carried out in manufacturing sector .There are many removal processes for the work piece such as drilling, turning ,etc.Therefore the given statement in the question is true.
During the discharge ions combine with anode to form a compound and release one or more electron.
