This acronym is a reminder of the most common types of hazards or injuries caused by electricity.

A long corridor has a single light bulb and two doors with light switch at each door.

Tpy6a [65]

Answer:

Light = A xor B

Explanation:

If switches A and B produce True or False, then Light will be True for ...

Light = A xor B

8 0

3 years ago

What is your name in face book

nekit [7.7K]

Answer:

Why do you want to know...?

4 0

3 years ago

Read 2 more answers

A 50 Hz, four pole turbo-generator rated 100 MVA, 11 kV has an inertia constant of 8.0 MJ/MVA. (a) Find the stored energy in the

raketka [301]

Given Information:

Frequency = f = 60 Hz

Complex rated power = G = 100 MVA

Intertia constant = H = 8 MJ/MVA

Mechanical power = Pmech = 80 MW

Electrical power = Pelec = 50 MW

Number of poles = P = 4

No. of cycles = 10

Required Information:

(a) stored energy = ?

(b) rotor acceleration = ?

(c) change in torque angle = ?

(c) rotor speed = ?

Answer:

(a) stored energy = 800 Mj

(b) rotor acceleration = 337.46 elec deg/s²

(c) change in torque angle (in elec deg) = 6.75 elec deg

(c) change in torque angle (in rmp/s) = 28.12 rpm/s

(c) rotor speed = 1505.62 rpm

Explanation:

(a) Find the stored energy in the rotor at synchronous speed.

The stored energy is given by

$E = G \times H$

Where G represents complex rated power and H is the inertia constant of turbo-generator.

$E = 100 \times 8 \\\\E = 800 \: MJ$

(b) If the mechanical input is suddenly raised to 80 MW for an electrical load of 50 MW, find rotor acceleration, neglecting mechanical and electrical losses.

The rotor acceleration is given by

$P_a = P_{mech} - P_{elec} = M \frac{d^2 \delta}{dt^2}$

Where M is given by

$M = \frac{E}{180 \times f}$

$M = \frac{800}{180 \times 50}$

$M = 0.0889 \: MJ \cdot s/ elec \: \: deg$

So, the rotor acceleration is

$P_a = 80 - 50 = 0.0889 \frac{d^2 \delta}{dt^2}$

$30 = 0.0889 \frac{d^2 \delta}{dt^2}$

$\frac{d^2 \delta}{dt^2} = \frac{30}{0.0889}$

$\frac{d^2 \delta}{dt^2} = 337.46 \:\: elec \: deg/s^2$

(c) If the acceleration calculated in part(b) is maintained for 10 cycles, find the change in torque angle and rotor speed in revolutions per minute at the end of this period.

The change in torque angle is given by

$\Delta \delta = \frac{1}{2} \cdot \frac{d^2 \delta}{dt^2}\cdot (t)^2$

Where t is given by

$1 \: cycle = 1/f = 1/50 \\\\10 \: cycles = 10/50 = 0.2 \\\\t = 0.2 \: sec$

So,

$\Delta \delta = \frac{1}{2} \cdot 337.46 \cdot (0.2)^2$

$$ \Delta \delta = 6.75 \: elec \: deg$

The change in torque in rpm/s is given by

$\Delta \delta = \frac{337.46 \cdot 60}{2 \cdot 360\circ }$

$\Delta \delta =28.12 \: \: rpm/s$

The rotor speed in revolutions per minute at the end of this period (10 cycles) is given by

$Rotor \: speed = \frac{120 \cdot f}{P} + (\Delta \delta)\cdot t$

Where P is the number of poles of the turbo-generator.

$Rotor \: speed = \frac{120 \cdot 50}{4} + (28.12)\cdot 0.2$

$Rotor \: speed = 1500 + 5.62$

$$ Rotor \: speed = 1505.62 \:\: rpm$

4 0

3 years ago

What is the most common injury caused by working with machines unsafely?

VladimirAG [237]

Answer:

heyooo!!!!!!

Burns and scarring.

hope this helps!!!!

Explanation:

8 0

3 years ago

Read 2 more answers

5. The water in an 8-m-diameter, 3-m-high above-ground swimming pool is to be emptied by unplugging a 3-cm-diameter, 25-m-long h

frosja888 [35]

Answer:

The maximum discharge rate of water through the pipe is 0.00545 m³/s or 5.45 L/s.

Friction head and pressure head will cause the actual flow rate to be less.

Explanation:

Considering point 1 at the free surface of the pool, and point 2 at the exit of

pipe.

Using Bernoulli equation between

these two points simplifies to

P1/(p*g) + V1²/2g + z1 = P2/(p*g) + V2²/2g + z2

Let the reference level at the pipe exit (z2 = 0). Noting that the fluid at both points is open to the atmosphere (and thus P1 = P2 = Patm) and that the fluid velocity at the free surface is very low (V1 ≅ 0),

P/(p*g) + z1 = P/(p*g) + V2²/2g

z1 = V2²/2g

Note; z1 = h

V2max = √2gh

h = 3 m

V2max = √2 * 9.81 * 3

V2max = √58.86 = 7.67 m/s

maximum discharge rate of water through the pipe Qmax = Area A * Velocity of discharge V2max

Qmax = A * V2max

Diameter d = 3 cm = 0.03 m

A = Πd²/4 = (Π * 0.03²)/4 = 0.00071m³

Qmax = 0.00071 * 7.67 = 0.00545 m³/s

Qmax = 5.45 L/s

The maximum discharge rate of water through the pipe is 0.00545 m³/s or 5.45 L/s.

Actual flow rate will be less because of heads such as friction head and pressure head.

7 0

3 years ago
