Question

Kindly Don't Spàm!Thank uh !:)xFormula1" title=" \\ \\ \\ \\ " alt=" \\ \\ \\ \\ " align="absmiddle" class="latex-formula">
​

Answer 1

.

$\: \underline{ \boxed{ { \color{gray}\frak{\huge \: Answer : }}}}$

Collector Current at Saturation :

• $\sf \large {I_{C(SAT)} = \frac{ V_{CC} }{R_C} }$

$\: \:$

• $\sf \large {I_{C(SAT)} = \frac{12}{2.2 \times 10 ^{3} } }$

$\: \:$

• $\bold{ \bf \large {I_{C(SAT)} =5.45mA }}$

$\: \:$

________________________________

Value Of Cut - off Voltage :

• $\sf \large \: V_{CS(cut-off)} = V_{CC}$

$\: \:$

Therefore ,

$\: \:$

• $\bf \large \: V_{CS(cut-off)} = \: 12v$

$\: \:$

________________________________

${ \bf\large \: Base \: Current , I_B = \frac{V_{CC}}{R_C} }$

• $\sf \large \: I_B ={ \frac{12}{2.2 \times 10 ^{3} } }$

$\: \:$

• $\bf \large \: I_B = 50μA$

$\: \:$

_______________________________

Collector Current ,

• $\sf \large \: I_C = β * I_B$

$\: \:$

• $\sf \large \: I_C = 50 * 50 * 10^{-6}$

$\: \:$

• $\bf \large \: I_C = 2.5mA$

$\: \:$

________________________________

Collector to emitter Voltage :

• $\sf \large \: V_{CE} = V_{CC} - ( I_C * R_C )$

$\: \: \:$

• $\sf \large \: V_{CE} = 12 - ( 2.5 * 10-³ * 2.2 * 10³ )$

$\: \:$

• $\bf \large \: V_{CE} = 6.5v$

________________________________

Q - point are :

• $\sf \large \: I_{CEQ} = 2.5mA$

$\: \:$

• $\sf \large \: V_{CEQ} = 6.5v$

________________________________

Q - point located on the DC load line as shown in fig ~

________________________________

Hope Helps!:)

$\: \: \: \:$
