Answer:
The answer is The Cache Sets (S) = 32, Tag bits (t)=24, Set index bits(s) = 5 and Block offset bits (b) = 3
Explanation:
Solution
Given Data:
Physical address = 32 bit (memory address)
Cache size = 1024 bytes
Block size = 8 bytes
Now
It is a 4 way set associative mapping, so the set size becomes 4 blocks.
Thus
Number of blocks = cache size/block size
=1024/8
=128
The number of blocks = 128
=2^7
The number of sets = No of blocks/set size
=128/4
= 32
Hence the number of sets = 32
←Block ←number→
Tag → Set number→Block offset
←32 bit→
Now, =
The block offset = Log₂ (block size)
=Log₂⁸ = Log₂^2^3 =3
Then
Set number pc nothing but set index number
Set number = Log₂ (sets) = log₂³² =5
The remaining bits are tag bits.
Thus
Tag bits = Memory -Address Bits- (Block offset bits + set number bits)
= 32 - (3+5)
=32-8
=24
So,
Tag bits = 24
Therefore
The Cache Sets = 32
Tag bits =24
Set index bits = 5
Block offset bits = 3
Note: ←32 bits→
Tag 24 → Set index 5→Block offset 3
Pentium is just a brand of a CPU chips from Intel that is usually in your laptops or chromebooks. It's used for general purpose computing. Produced by Intel since 1993.
Applying potential difference to a conductor, by potential force, free electrons gain energy and move from low to high potential. Thus, electrons move from one atom to another.
Answer:
The answer to this question is given below in the explanation section.
Explanation:
STEM is a curriculum based on the idea of educating students in four specific disciplines — science, technology, engineering, and mathematics — in an interdisciplinary and applied approach. The students who graduated in STEM-based education getting more paid and jobs than students who did not study the STEM-based education.
As in this question that John is considering his STEM education choices, and he wants to begin working in the technology field as soon as possible. He should pursue bachelor (graduate) degree in technology. Because after, passing out, he can begin working in technology easily.
