Answer:
Explanation:
Given that,
Number of turns of coil
N = 50 turns
Initial area of plane
A1 = 0.18 m²
The coil it stretch to a no area in time t = 0.1s
No area implies that the final area is 0, A2 = 0 m²
Constant magnetic field strength
B = 1.51 T
EMF?
EMF is given as
Using far away Lenz law
ε = —N• dΦ/dt
Where Φ = BA
Then,
ε = —N• d(BA)/dt
Since B is constant,
ε = —N•B dA/dt
ε = —N•B (∆A/∆t)
ε = —N•B(A2—A1)/(t2-t1)
ε = —50 × 1.51 (0—0.18)/(0.1—0)
ε =—75.5 × —0.18 / 0.1
ε = 135.9 V
The induced EMF is 135.9V
Fleming’s left hand rule stated that if the index finger points toward magnetic flux, the thumb towards the motion of the conductor, then the middle finger points towards the induced emf.
Since the area lines in the plane, then the induced emf will be out of the page
Answer:
Ideal machines are said to have parts which are weightless , frictionless and strings if any are inextensible. Practical machines have parts which have weights, friction and it causes some loss of work done.
Explanation:
Answer:
I think the answer is 18 km/h
Explanation:
The b<span>ottom one because it has longer wavelengths and because the bottom ones has 3 wavelengths</span>
