The formal charge is the "charge" an element would have in a molecule or ion if all of the bonding electrons were shared equally
between atoms.We can draw three inequivalent Lewis structures for the thiocyanate ion , SCN- . The concepts of formal charge and electronegativity can help us choose the structure that is the best representation.1. Assign formal charges to the elements in each of the structures below.ABCFormal ChargeSCN-12010-100-12. The best Lewis structure for SCN- is .
1 answer:
You might be interested in
Answer: The Lewis structure of Chloroacetate can be found at the attachment below.
Explanation:
CH2ClCOO- The chemical compound is called Chloroacetate.
Reference link for the Chloroacetate structure.
https://www.google.com/search?q=lewis+structure+for+CH2ClCOO-&prmd=ivn&sxsrf=ALeKk03mQcLiY-q5pEriMR0_26ZTXLjmJg:1589680325594&source=lnms&tbm=isch&sa=X&ved=2ahUKEwjfxPPY5LnpAhVloXEKHeAwD-wQ_AUoAXoECA4QAQ&cshid=1589680746615&biw=360&bih=559&dpr=3#
Answer:
0.4 g of hydrogen gas would be produced.
1. 0.48 mole of HCl is needed to react completely with 15.5 g of zinc.
2. HCl is the limiting reactant.
3. 2.61 g of zinc is in excess
Explanation:
From the balanced equation of reaction:
1 mole of Zn requires 2 moles of HCl to produce 1 mole of hydrogen gas.
15.5 g of zinc = 15.5/65.3 = 0.24 moles of zinc.
0.24 moles Zn is supposed to require 0.24 x 2 moles HCl which is equivalent to 0.48 moles HCl.
But only 0.400 mole of HCl is present. <u>Hence, HCl is the limiting reagent</u>. <u>For complete reaction with 15.5 g of Zinc, 0.48 mole HCl would be needed.</u>
0.400 mole of HCl will require 0.2 mole of Zn for complete reaction. <u>This thus means that 0.24 - 02 = 0.04 mole of Zn is in excess.</u>
0.04 mole Zn = 0.04 x 65.3 = 2.61 g excess Zn.
Now, since HCl is the limiting reagent;
2 moles of HCl is required to produce 1 mole of H2 according to the equation.
0.400 mole HCl will therefore yield 0.400 x 1/2 = 0.2 mole H2
0.2 mole H2 = 2 x 0.2 = 0.4 g H2
<em>Hence, </em><em>0.4 g</em><em> of hydrogen gas would be produced.</em>
The electron configuration of lithium atom is: ![Li:[He]2s^1](https://tex.z-dn.net/?f=Li%3A%5BHe%5D2s%5E1)
The number "2" is the value of the principal quantum number "n". Letter "s" is associated with the value of secondary quantum number "l" and it is equal to zero. The value of "m" (or magnetic quantum number) is zero too. The quantum number set for the highest energy electron will be (2, 0, 0, 1/2).
The number "2" is the value of the principal quantum number "n". Letter "s" is associated with the value of secondary quantum number "l" and it is equal to zero. The value of "m" (or magnetic quantum number) is zero too. The quantum number set for the highest energy electron will be (2, 0, 0, 1/2).
