Answer:
(a)T= M2 × g, (b)T= (M1 + M2)g, (c)T= M2 (a + g) and (d)T=(M1 + M2) (a + g)
Explanation:
M1 is hanged upper and M2 is lower at Rest.
(a) For M2
T2 = Weight of the Body M2= M2 × g
(b) T1 = Weight of the Body M2 + Weight of the Body M2
T1 = M1 g + M2 g = (M1 + M2)g
M1 is hanged upper and M2 is lower at accelerated upwards ( F = T - W)
(c) For M2
⇒T = M2a + M2g = M2 (a + g)
(d) For M1
T = (M1 + M2) a + (M1 + M2) g
⇒ T = (M1 + M2) (a + g)
Electric field lines of positive charges are always radially outwards
So here all field lines must have tendency to move out radially as well as two field lines never intersects with each other
So here field lines also do not intersects with each other
So overall the figure C is perfectly representing the field lines of two positive charges as these lines are not intersecting and also originating from two positive charges.
So answer must be
<u><em>FIGURE C</em></u>
a) 1.57 m/s
The sock spins once every 2.0 seconds, so its period is
T = 2.0 s
Therefore, the angular velocity of the sock is

The linear speed of the sock is given by

where
is the angular velocity
r = 0.50 m is the radius of the circular path of the sock
Substituting, we find:

B) Faster
In this case, the drum is twice as wide, so the new radius of the circular path of the sock is twice the previous one:

At the same time, the drum spins at the same frequency as before, therefore the angular frequency as not changed:

Therefore, the new linear speed would be:

And substituting,

So, we see that the linear speed has doubled.
Explanation:
rigidibiyu. jtibiti vekov oeo i irki jri kri oro lro
To solve the problem it is necessary to apply the concepts related to the voltage in a coil, through the percentage relationship that exists between the voltage and the number of turns it has.
So things our data are given by



PART A) Since it is a system in equilibrium the relationship between the two transformers would be given by

So the voltage for transformer 2 would be given by,

PART B) To express the number value we proceed to replace with the previously given values, that is to say
