Consider a 20-cm X 20-cm X 20-cm cubical body at 477°C suspended in the air. Assuming the body closely approximates a blackbody,

determine
(a) the rate at which the cube emits radiation energy, in W and
(b) the spectral blackbody emissive power at a wavelength of 4 µm.
Engineering
1 answer:
Olin [163]4 years ago
8 0

Answer:

a) The rate at which the cube emits radiation energy is 704.48 W

b) The spectral blackbody emissive power is 194.27 W/m²μm

Explanation:

Given data:

a = side of the cube = 0.2 m

T = temperature = 477°C

Wavelength = 4 µm

a) The surface area is:

A_{s} =6a^{2} =6(0.2)^{2} =0.24m^{2}

According Stefan-Boltzman law, the rate of emission is:

E=\sigma T^{4} A_{s} =5.67x10^{-8} *(477)^{4} *0.24=704.48W

b) Using Plank´s distribution law to get the spectral blackbody emissive power.

E=\frac{C_{1} }{\lambda ^{5}(exp(\frac{C_{2} }{\lambda T}) -1 )} =\frac{3.743x10^{8} }{4^{5}(exp(\frac{1.4387x10x^{4} }{4*477})-1)  } =194.27W/m^{2} \mu m

You might be interested in
Help please its due today will mark you brainliest
Tems11 [23]

Answer:

launch- The first stage is ignited at launch and burns through the powered ascent until its propellants are exhausted. The first stage engine is then extinguished, the second stage separates from the first stage, and the second stage engine is ignited. The payload is carried atop the second stage into orbit

powered ascent-The first stage is ignited at launch and burns through the powered ascent until its propellants are exhausted. The first stage engine is then extinguished, the second stage separates from the first stage, and the second stage engine is ignited. The payload is carried atop the second stage into orbit

coasting flight-

When the rocket runs out of fuel, it enters a coasting flight. The vehicle slows down under the action of the weight and drag since there is no longer any thrust present. The rocket eventually reaches some maximum altitude which you can measure using some simple length and angle measurements and trigonometry.

ejection charge-At the end of the delay charge, an ejection charge is ignited which pressurizes the body tube, blows the nose cap off, and deploys the parachute. The rocket then begins a slow descent under parachute to a recovery. The forces at work here are the weight of the vehicle and the drag of the parachute.

slow decent- slow downs (i guess)

recovery-A recovery period is typically characterized by abnormally high levels of growth in real gross domestic product, employment, corporate profits, and other indicators. This is a turning point from contraction to expansion and often results in an increase in consumer confidence

Explanation:

6 0
4 years ago
3. A 4-m × 5-m × 7-m room is heated by the radiator of a steam-heating system. The steam radiator transfers heat at a rate of 10
Natali [406]

Answer:

14.52 minutes

<u>OR</u>

14 minutes and 31 seconds

Explanation:

Let's first start by mentioning the specific heat of air at constant volume. We consider constant volume and NOT constant pressure because the volume of the room remains constant while pressure may vary.

Specific heat at constant volume at 27°C = 0.718 kJ/kg*K

Initial temperature of room (in kelvin) = 283.15 K

Final temperature (required) of room = 293.15 K

Mass of air in room= volume * density= (4 * 5 * 7) * (1.204 kg/m3) = 168.56kg

Heat required at constant volume: 0.718 * (change in temp) * (mass of air)

Heat required = 0.718 * (293.15 - 283.15) * (168.56) = 1,210.26 kJ

Time taken for temperature rise: heat required / (rate of heat change)

Where rate of heat change = 10000 - 5000 = 5000 kJ/hr

Time taken = 1210.26 / 5000 = 0.24205 hours

Converted to minutes = 0.24205 * 60 = 14.52 minutes

4 0
4 years ago
A hair dryer is basically a duct of constant diameter in which a few layers of electric resistors are placed. A small fan pulls
Inessa05 [86]

Answer:

the percent increase in the velocity of air is 25.65%

Explanation:

Hello!

The first thing we must consider to solve this problem is the continuity equation that states that the amount of mass flow that enters a system is the same as what should come out.

m1=m2

Now remember that mass flow is given by the product of density, cross-sectional area and velocity

(α1)(V1)(A1)=(α2)(V2)(A2)

where

α=density

V=velocity

A=area

Now we can assume that the input and output areas are equal

(α1)(V1)=(α2)(V2)

\frac{V2}{V1} =\frac{\alpha1 }{\alpha 2}

Now we can use the equation that defines the percentage of increase, in this case for speed

i=(\frac{V2}{V1} -1) 100

Now we use the equation obtained in the previous step, and replace values

i=(\frac{\alpha1 }{\alpha 2} -1) 100\\i=(\frac{1.2}{0.955} -1) 100=25.65

the percent increase in the velocity of air is 25.65%

6 0
3 years ago
Does a general repair <br> manual have the answers to all repairs?
uranmaximum [27]

Explanation:

yes it has the answers to all repairs

4 0
3 years ago
Dimension these please.
Svetach [21]

Answer:

86

Explanation:

3 0
3 years ago
