Naddik [55]
3 years ago
8

Find the magnitude and direction of 101m,63.5m,57.0

Physics
1 answer:
Sliva [168]3 years ago
4 0

Answer:

  158.085∠69.6°

Explanation:

The most straightforward way to work these is to convert them to rectangular coordinates and back. It looks like you may have several problems of this nature, so it may work well for you to do the calculations using a spreadsheet. That way, you can just change the numbers for a new problem, and not have to mess with the formulas.

For magnitude m at angle a, the rectangular coordinates are ...

  m∠a = (x, y) = (m·cos(a), m·sin(a))

For these two vectors, the rectangular coordinates are ...

  A = (0, 63.5)

  B = (101·cos(57°), 101·sin(57°)) ≈ (55.0085, 84.7057)

Then the sum is ...

  A + B = (0 +55.0085, 63.5 +84.7057) = (55.0085, 148.2057)

___

The conversion back to polar coordinates is ...

  m = √(x²+y²)

  a = arctan(y/x) . . . . paying attention to quadrant based on the signs*

For this sum,

  m = √(55.0085² +148.2057²) ≈ √24990.9 ≈ 158.085

  a = arctan(148.2057/55.0085) ≈ arctan(2.69423) ≈ 69.6°

So, the sum is ...

  A + B ≈ 158.085∠69.6°

_____

* If you do this using a spreadsheet, the ATAN2 function chooses the quadrant based on the signs of the two arguments. Note that results may be in radians, so may require conversion to degrees. (You may also have to convert degrees to radians for the sine and cosine functions.)

You might be interested in
A block has two strings attached to it on opposite ends. One string has a force of 5 N,
juin [17]

Unless you have a diagram to include or any other additional info, I'll assume the block is being pulled by two opposing forces along the horizontal surface.

Horizontally, the block is under the influence of

• one rope pulling in one direction with magnitude 15 N,

• the other rope pulling in the opposite direction with mag. 5 N, and

• friction, opposing the direction of the block's motion, with mag. 3 N.

It stands to reason that the block is accelerating in the direction of the larger pulling force.

(A) By Newton's second law, we have

15 N + (-5 N) + (-3 N) = <em>m</em> (1 m/s²)

where <em>m</em> is the mass of the block. Solve for <em>m</em> :

7 N = <em>m</em> (1 m/s²)

<em>m</em> = (7 N) / (1 m/s²)

<em>m</em> = 7 kg

(B) The friction force is proportional to the normal force, so that if <em>f</em> is the mag. of friction and <em>n</em> is the mag. of the normal force, then <em>f</em> = <em>µ</em> <em>n</em> where <em>µ</em> is the coefficient of friction.

The block does not bounce up and down, so its vertical forces are balanced, which means the normal force and the block's weight (mag. <em>w</em>) cancel out:

<em>n</em> + (-<em>w</em>) = 0

<em>n</em> = <em>w</em>

<em>n</em> = <em>m</em> <em>g</em>

where <em>g</em> = 9.8 m/s² is the mag. of the acceleration due to gravity.

<em>n</em> = (7 kg) (9.8 m/s²)

<em>n</em> = 68.6 N

Then

3 N = <em>µ</em> (68.6 N)

<em>µ</em> = (3 N) / (68.6 N)

<em>µ</em> ≈ 0.044

4 0
3 years ago
How can a calculated height be greater than an actual height?
sammy [17]

Answer:

mesuring heigh and weight is important

3 0
3 years ago
What is the equation for potential energy?
Mrrafil [7]
You can calculate potential energy by:
U = m.g.h

Where, U = potential energy
m = mass
g = acceleration due to gravity
h = height

Hope this helps!
7 0
4 years ago
Read 2 more answers
A 26.0 kg child plays on a swing having support ropes that are 2.40 m long. A friend pulls her back until the ropes are 45.0 ∘ f
Sloan [31]
A)Ep'=mgh=mgl(1-cosa).At the bottom of the swing Ep=0(reference level),so the potential energy as the child is just released is bigger than the potential energy at the bottom of the swing.;B)The speed of the child at the bottom of the swing-->v=√(2gh)=√[2gl(1-cosa)];C)I don't think that the tension does any work.
8 0
3 years ago
HELP
Mila [183]

Answer: When you break on your bike and when you rub your hands together to get warm.

Explanation: Force and friction affect our daily lives in numerous amounts of ways. For instance, when a football is kicked, it moves faster later after some time its force decreases due to friction. A common example of friciton is when a bike stops. When the brakes are applied the friction on the pads cause the bike to stop. The rubbing hands is making friction. Which makes you get warm.

5 0
3 years ago
