What are the common approximations made in the analysis of heat exchangers?
1 answer:
You might be interested in
Answer:
hello your question is incomplete attached below is the complete question
answer :
Slopes : B = 180 mm , C = 373 mm
Deflection: B = 0.0514 rad , C = 0.077 rad
Explanation:
Given data :
I = 500(10^6) mm^4
E = 70 GPa
The M / EI diagram is attached below
<u><em>Deflection angle at B</em></u>
∅B = ∅BA = [ 150 (6) + 1/2 (300)*6 ] / EI
= 1800 / ( 500 * 70 ) = 0.0514 rad
<u><em>slope at B </em></u>
ΔB = ΔBA = [ 150(6)*3 + 1/2 (300)*6*4 ] / EI
= 6300 / ( 500 * 70 ) = 0.18 m = 180 mm
<u><em>Deflection angle at C </em></u>
∅C = ∅CA = [ 1800 + 300*3 ] / EI
= 2700 / ( 500 * 70 )
= 2700 / 35000 = 0.077 rad
<u><em>Slope at C </em></u>
ΔC = [ 150 * 6 * 6 + 1/2 (800)*6*7 + 300(3) *1.5 ]
= 13050 / 35000 = 373 mm
