Answer:
at resonance impedence is equal to resistance and quality factor is dependent on R L AND C all
Explanation:
we know that for series RLC circuit impedance is given by
but we know that at resonance
putting in impedance formula , impedance will become
Z=R so at resonance impedance of series RLC is equal to resistance only
now quality factor of series resonance is given by
so from given expression it is clear that quality factor depends on R L and C
Answer:
d= 1.56 m
Explanation:
In order to have a constructive interference, the path difference between the sources of the sound, must be equal to an even multiple of the semi-wavelength, as follows:
⇒ d = d₂ - d₁ = 2n*(λ/2)
The minimum possible value for this distance, is when n=1, as it can be seen here:
dmin = λ
In any wave, there exists a fixed relationship between the wave speed, the frequency and the wavelength:
v = λ*f
If v = vsound = 343 m/s, and f = 220 1/s, we can solve for λ:
λ =
⇒ dmin =λ = 1.56 m
