Can somebody help me

For an automotive spark-ignition engine, the combustion duration (from time of ignition through completion) is approximately one

Trava [24]

Answer:

1.72

Explanation:

Given that:

Engine speed = 600 rev/min

Crankshaft speed = 3000 rev/min

The mass rate must increase by a factor of 1.72 compared to the rate of conversion at 600 rev/min

5 0

3 years ago

Find the phasor form of:

mixer [17]

Answer:

$I=24.598\angle 50.377$

Explanation:

A tension or current expressed in cosine form and with a positive sign can be converted directly into a phasor. This is done by indicating the tension and the offset angle:

$Acos(10\omega t +\phi)=A\angle \phi$

So:

$i(t)=10cos(10t+63)+15cos(10t-42)=10\angle 63 + 15\angle42=I$

You can sum the phasors simply using a calculator, however, let's do it manually:

Let's find the rectangular form of each phasor using the next formulas:

$A=\sqrt{a^2+b^2} \\\phi=arctan(\frac{b}{a})$

For $10\angle 63$

$63=arctan(\frac{b}{a} )\\\\tan(63)=\frac{b}{a} \\\\b=a*tan(63)$

$10=\sqrt{a^2+(a*tan(63))^2} \\\\10^2=a^2+a^2*(tan(63))^2\\\\Solving\hspace{3}for\hspace{3}a\\\\a=\sqrt{\frac{100}{1+tan(63)^2} } =4.539904997\\\\and\hspace{3}b\\b=\sqrt{100-a^2} =8.910065242$

So:

$Z_1=a+bj=4.539904997+8.910065242j$

For $15\angle 42$

$42=arctan(\frac{b_2}{a_2} )\\\\tan(42)=\frac{b_2}{a_2} \\\\b_2=a_2*tan(42)$

$15=\sqrt{a_2^2+(a_2*tan(42))^2} \\\\15^2=a_2^2+a_2^2*(tan(42))^2\\\\Solving\hspace{3}for\hspace{3}a_2\\\\a_2=\sqrt{\frac{225}{1+tan(42)^2} } =11.14717238\\\\and\hspace{3}b_2\\\\b_2=\sqrt{225-a^2} =10.0369591$
