I need help plz <br><br> Drag each label to the correct location on the image.

The soil borrow material to be used to construct a highway embankment has a mass unit weight of 107.0 lb/cf and a water content

MrRissso [65]

Answer:

Option D

Explanation:

Given information

Bulk unit weight of 107.0 lb/cf

Water content of 7.3%,=0.073

Specific gravity of the soil solids is 2.62

Specifications

Dry unit weight is 113 lb/cf

Water content is 6%.

Volume of embankment is 440,000-cy

Borrow material

$Dry_{unit,weight}=\frac {bulk_{unit,weight}}{1+water_{content}}=\frac {107}{1+0.073}= 99.72041 lb/cf$

Embankment

Considering that the volume of embankment is inversely proportional to the dry unit weight

$\frac {V_{embankment}}{V_{borrow}}=\frac {Dry_{borrow}}{Dry_{embankment}}$

Therefore, $V_{borrow}=V_{embankment} *\frac {Dry_{embarkement}}{Dry_{borrow}}$

$V_{borrow}=440,000-cy*\frac {113 lb/cf }{99.72041 lb/cf }= 498594-cy$

Therefore, volume of borrow material is 498594-cy

(b)

The weight of water in embankment is found by multiplying the moisture content and dry unit weight.

Assuming that all the specifications are achieved, weight of water in embankment=0.06*113=6.78 lb/cf

Since $1 yd^{3}= 27 ft^{3}$

The embankment requires water of 6.78*27*440000= 80546400 lb

Borrow materials’ water will also be 0.073*99.72041=7.27959 lb/cf

Borrow material requires water of 7.27959*27*498594=97998120 lb

Extra water between borrow material and embankment=97998120 lb-80546400 lb=17451720 lb

$Unit_{weight}=\frac {17451720}{498594}=35.00186 lb$

1 gallon is approximately $8.35 yd^{3}$ hence

$\frac {35.00186 lb/yd^{3}}{8.35}=4.19184 gallons/yd^{3}$

That's approximately 4.2 gallons

7 0

3 years ago

Which bulb has the lowest total cost of operation? (a) Incandescent (b) Fluorescent (c) LED

Finger [1]

Answer: LED have the lowest cost of operation.

Explanation:

If we ignore the initial procurement cost of the items the operational cost of any device consuming electricity is given by

$Cost=Energy\times cost/unit$

Among the three item's LED consumes the lowest power to give the same level of brightness as compared to the other 2 item's thus LED's shall have the lowest operational cost.

6 0

4 years ago

technician a says that the higher the gear selected the more torque is available. technician b says that a transaxle contains ge

umka21 [38]

Technician A is correct. Technician B is wrong because a gear's transmission is used to increase or decrease torque.

The relation torque is relying on multiplying the circumferential detail with the resource of the usage of the radius; massive gears experience a greater amount of torque, at the same time as smaller gears experience a great deal much less torque. Similarly, the torque ratio is equal to the ratio of the gears' radii. A gear's transmission torque modifications as it will boom or decreases speed. Commonly, with the resource of the usage of lowering the speed, a small torque on the doorway issue is transferred as a massive torque at the output issue. The calculation of torque is quantified with the resource of the usage of an extensive form of teeth.

Learn more about the torque at brainly.com/question/28220969

#SPJ4

3 0

1 year ago

"At 195 miles long, and with 7,325 miles of coastline, the Chesapeake Bay is the largest and most complex estuary in the United

Paraphin [41]

Answer:

see explaination

Explanation:

Part a) Width of bay at Potomac River:

Given Data:

· Actual Width at Potomac River = 30 miles

· Bay Model Length Ratio Lr = 1/1000

In fluid mechanics models of real structures are prepared in simulation so that they can be analyzed accurately. A model is known to have simulation if model carries same geometric, kinematic and dynamic properties at a small scale.

Length of any part in model = Actual length x Lr

Hence,

Model Width of bay at Potomac River = 30 x 1/1000 = 0.03 miles

Since 1 mile = 5280 ft

Model Width of bay at Potomac River = 0.03 x 5280 = 158.4 ft

Part b) Model Length of bay bridge in model:

Given Data:

· Actual Length of bay bridge = 4.3 miles

· Bay Model Length Ratio Lr = 1/1000

Model Length = Actual Length x Lr = 4.3 x 1/1000 = 0.0043 miles

Since 1 mile = 5280 ft

Model Length in feet = 0.0043 x 5280 = 22.704 ft

Part c) Model Length of bay bridge in model:

Given Data:

· Model Area = 8 acre

· Bay Model Length Ratio Lr = 1/1000

Model Area = Actual Area x Lr x Lr

8 Model Area :: Actual Area =- (Lp)2 2 = 8,000,000 acre 1000

Since 1 square mile = 640 acre,

Actual Area in square miles = 8,000,000/640 = 12,500 square miles

Part d) Average and maximum depth of model:

Given Data:

· Actual Average depth = 28 ft

· Actual Maximum depth = 174 ft

· Bay Model Length Ratio Lr = 1/1000

Model average depth = Actual average depth x Lr = 28 x 1/1000 = 0.028 feet

Since 1 ft = 12 inch

Model average depth in inch = 0.028 x 12 = 0.336 in

Model maximum depth = Actual maximum depth x Lr = 174 x 1/1000 = 0.174 feet

Since 1 ft = 12 inch

Model maximum depth in inch = 0.174 x 12 = 2.088 in

4 0

3 years ago

Briefly explain how a jet moves

sergejj [24]

Answer:

Jet engines move the airplane forward with a great force that is produced by a tremendous thrust and causes the plane to fly very fast. All jet engines, which are also called gas turbines, work on the same principle. The engine sucks air in at the front with a fan. ... Spinning the turbine causes the compressor to spin.

Explanation:

yw

8 0

3 years ago

I need help plz Drag each label to the correct location on the image.
