My model is supposed to have

A diffraction pattern forms when light passes through a single slit. The wavelength of the light is 691 nm. Determine the angle

expeople1 [14]

Explanation:

Given that,

Wavelength of the light, $\lambda=691\ nm=691\times 10^{-9}\ m$

(a) Slit width, $a=3.8\times 10^{-4}\ m$

The angle that locates the first dark fringe is given by :

$sin\theta=\dfrac{\lambda}{a}$

$sin\theta=\dfrac{691\times 10^{-9}}{3.8\times 10^{-4}}$

$\theta=0.104^{\circ}$

(b) Slit width, $a=3.8\times 10^{-6}\ m$

The angle that locates the first dark fringe is given by :

$sin\theta=\dfrac{\lambda}{a}$

$sin\theta=\dfrac{691\times 10^{-9}}{3.8\times 10^{-6}}$

$\theta=10.47^{\circ}$

Hence, this is the required solution.

7 0

4 years ago

An airplane in a holding pattern flies at constant altitude along a circular path of radius 3.38 km. If the airplane rounds half

Andrej [43]

Answer:

a) 6076 m

b) 43.33 m/s

c) 68 m/s

Explanation:

(a) If the airplane rounds half the circle in 156s, its displacement is the circle diameter in 156s, or twice the circle's radius

s = 2r = 2* 3.38km = 6.76 km or 6760 m

(b) The average velocity would be displacement over unit of time

v = s/t = 6760 / 156 = 43.33 m/s

(c) The length of the chord it's swept in 156s is half of the circle perimeter

c = πr = π3.38 = 10.62 km or 10620 m

The airplane average speed is its chord length over a unit of time

c / t = c / 156 = 68 m/s

4 0

3 years ago

Balboa Park in San Diego has an outdoor organ. When the air temperature increases, the fundamental frequency of one of the organ

musickatia [10]

The fundamental frequency of one of the organ pipes will go up or increase.

When pressured air is forced into an organ pipe, it echoes at a particular pitch, generating the sound of the pipe organ. Each pipe has been adjusted to a particular pitch on the musical scale.

A musical instrument called an outdoor pipe organ is used to perform music. It produces some calming tones and has a really serene sound. The organ pipe produces the sound of the outdoor organ. The wavelength of the sound is also dependent on the length of the pipe. The fundamental frequency of one of the organ pipes will grow as the speed of the sound increases as the ambient air temperature rises.

The correct option is (c).

Learn more about frequency here:

brainly.com/question/254161

#SPJ4

6 0

1 year ago

Which countries produce the most greenhouse gas emissions?

Kipish [7]

india and china produce the most greenhouse gas emissions?

7 0

3 years ago

In some circumstances, science will answer questions about what is good and what is evil.

Margaret [11]

False, its up to you to decide what you belive is right and what is wrong.

3 0

3 years ago
