Answer:
W= 4.4 J
Explanation
Elastic potential energy theory
If we have a spring of constant K to which a force F that produces a Δx deformation is applied, we apply Hooke's law:
F=K*x Formula (1): The force F applied to the spring is proportional to the deformation x of the spring.
As the force is variable to calculate the work we define an average force
Formula (2)
Ff: final force
Fi: initial force
The work done on the spring is :
W = Fa*Δx
Fa : average force
Δx : displacement
:Formula (3)
: final deformation
:initial deformation
Problem development
We calculate Ff and Fi , applying formula (1) :


We calculate average force applying formula (2):

We calculate the work done on the spring applying formula (3) : :
W= 11N*(0.7m-0.3m) = 11N*0.4m=4.4 N*m = 4.4 Joule = 4.4 J
Work done in stages
Work is the change of elastic potential energy (ΔEp)
W=ΔEp
ΔEp= Epf-Epi
Epf= final potential energy
Epi=initial potential energy




W=ΔEp= 5.39 J-0.99 J = 4.4J
:
Answer:
32 m/s
Explanation:
The speed of a bus is 30 m/s due East wrt the passenger
He also sees a passenger on the bus walking to the back at 2 m/s.
We need to find the passenger's velocity relative to the bus. As the observer sees that the bus and the passenger are moving in opposite direction. Let v is the relative velocity. So,
v = 30 m/s + 2 m/s
v = 32 m/s
Hence, the passenger's velocity relative to the bus is 32 m/s.
Answer:
6 voltage is applied by the batteries.
Explanation:
To solve this sort of problem involving current, resistance and voltage, we use the relation:<em> </em><em>Voltage</em><em>= </em><em>Current x Resistance</em>.
From the problem, the following have been given:
Resistance= 2.4 ohms.
Current= 2.5 amps.
Required: Voltage?
Fix the values of current and resistance into the relation:
Voltage= <em>2.5 x 2.4</em>
=6 volts.
Answer:
Optical Time Domain Reflector
Explanation:
Localized the break, supplies a graphical trace of where the break occurs in order to detect high loss splice point as far as 25 miles.
1.) Power, P = V²/R = 800²/45 = 4.5 W (A).
2.) Six Resistors in Series.
R = R1 + R2 + R3 + R4 + R5 + R6, Since R is the same, R = 20
R total = 6*20 = 120 (D)
3.) It is the current. Series connection is to evaluate current. (B)
