When a force causes a body to move, work is done on the object by the force. Work is the measure of the energy transfer when a force 'F' moves an object through a distance 'd'. So we say that energy is transferred from one energy store to another when work is done, and therefore, energy transferred = work done.
Answer:
R=4Ω
Explanation:
R1 and R3 are parrallel
so we have : R=R1*R2/R1+R2
R=6*3/6+3
R=18/9
R=2Ω
R2 and 2Ω are in series,so we have
R=R2+2
R=2+2
R=4Ω
Answer:
The question is incomplete as some details are missing, here is the details ;
In this final state
a) spheres #1 and #2 both carry negative charge.
b) sphere #1 carries negative charge and #2 carries positive charge.
c) spheres #1 and #2 are still uncharged.
d) sphere #1 carries positive charge and #2 carries negative charge.
e) spheres #1 and #2 both carry positive charge.
Explanation:
From the concept of electrostatics, if a positively charged sphere is brought close to #2, there will be attraction of the opposite charges(-ve) towards it.
Now connecting a copper wire between #1 and #2, opposite charges will flow from #1 towards #2. disconnecting the copper wire makes #1 to be positively charged and #2 to be negatively charge and from the laws of attraction ; Like charges repel and unlike charges attract. the correct option is d.
relation between potential difference and electric field is given as
so here we know that
d = 3 cm
So now when plates are separated to 4 cm distance carefully
the potential difference between them will change but the electric field between them will remain constant
So at distance of 4 cm also the electric field will be E = 1000 N/C
Answer:
the diameter of the smaller vessels is 9.90 mm
Explanation:
The computation of the diameter of the smaller vessels is given below;
Given that
The larger vessel of the diameter is 14mm
So,
d1 = 7 mm
let us assume the diameter of the smaller artery is d2
Now we used the equation of continuity i.e.
v × pi × d1^2 = 2 × v × pi × d2^2
14^2 = 2 × d2^2
d2 = 9.90 mm
Hence, the diameter of the smaller vessels is 9.90 mm
