What is the name given to the figure in which a line bisects two arrows pointed in

1 answer:

8 0

The name given to the figure in which a line bisects two arrows pointed in opposite directions would be a filled orbital.

The two arrows in opposing directions represent paired electrons while the bisecting line represents the orbital.

Each orbital can only take a maximum of two electrons and paired electrons usually have opposing orientations in the orbital - one spin up and the other spin down.

More on the orbital can be found here: brainly.com/question/18914648

You might be interested in

A bullet with a mass of 5.00 x 10^-3 kg is loaded into a gun. The loaded gun has a mass of 0.52 kg. The bullet is fired, causing

beks73 [17]

For the answer to the question above,
220 m/s
mass of the bullet * velocity of the bullet = mass of the gun * velocity of the gun
0.005 kg * v = 0.52 kg * 2.1 m/s
-> v = (0.52kg * 2.1 m/s) / 0.005 kg = 218.4 m/s
I hope my answer helped you. Have a nice day!

3 0

3 years ago

The heavyweight boxing champion of the world punches a sheet of paper in midair, bringing it from rest up to a speed of 26.5 m/s

enyata [817]

corrected question:The heavyweight boxing champion of the world punches a sheet of paper in midair, bringing it from rest up to a speed of 26.5 m/s in 0.044 s . The mass of the paper is 0.003 kg. Part A Find the force of the punch on the paper

Answer:

Force=1.8N

Explanation:

Newtons third law states that in every action there is equal and opposite reaction.

The force of the punch will be the force that moves the paper by a speed of 26.5m/s.

$F=ma$

$F=m\frac{v-u}{t}$

m=0.003kg , v=26.5m/s u=0(the paper is punched from rest) t=0.044s

$F=0.003*\frac{26.5-0.044}{0.044}$

F=1.8N

4 0

3 years ago

if a tank filled with water contains a block and the height of the water above point A within the block is 0.6meter, what's the

Fittoniya [83]

The pressure exerted by a fluid solely relies on the depth or height of the fluid, its density, and the gravitational constant. These three are related in the equation:

Pressure = density x g x height

In the problem, point A is within the block inside the tank. The water above the block is assumed to be 0.6 meters. This gives a point A pressure of:

P = 1000 kg/m^3 * 9.81 m/s^2 * 0.6 m = 5,886 Pa or 5.88KPa

6 0

3 years ago

Read 2 more answers

Two objects have the same velocity. These two objects have different masses. Which object will

kogti [31]

Answer:

The object with the greater mass will have the greater momentum

Explanation:

The momentum of an object with mass m, moving with velocity , is given by the formula

M = mv

Since both objects have the same velocity v, it is clear that the object with the bigger mass will have the greater momentum

6 0

2 years ago

Integrated Concepts A lightning bolt strikes a tree, moving 20.0 C of charge through a potential difference of 1.00×102 MV . (a)

vodka [1.7K]

Answer:

a) 2*10^9 J

b) 764.8 kg

Explanation:

Given that

Energy of charge, q = 20 C

Potential difference, ΔV = 1*10^2 MV = 1*10^2 * 10^6 V = 1*10^8 V

To find the energy dissipated, we use the formula

ΔU = qΔV

ΔU = 20 * 1*10^8

ΔU = 2*10^9 J

Change in temperature, ΔT = 100 - 15°

ΔT = 85° C

Change in energy, ΔU = 2*10^9 J

Specific heat of water, C = 4180 j./Kg.K

Latent heat of vaporization, L(v) = 2.26*10^6 J/Kg

Q1 = mcΔT

Q2 = mL(v)

Net energy needed, U = Q1 + Q2

U = mcΔT + mL(v)

U = m (cΔT + L(v))

m = U /[cΔT + L(v)]

Being that we have all the values, we then substitute

m = 2*10^9 / [(4180 * 85) + 2.26*10^6]

m = 2*10^9 / (3.553*10^5 + 2.26*10^6]

m = 2*10^9 / 2.615*10^6

m = 764.8 kg

Having 765 kg of steam at the temperature would have extreme effect on the tree, damaging it permanently. Possibly even blowing it to pieces

6 0
