a simple machine that combines two inclined planes and is used to split objects is called a . group of answer choices

Physics

1 answer:

Semmy [17]1 year ago

5 0

Answer:

The answer is a wedge.

Explanation:

The wedge is a combination of two inclined planes. It is used to separate bodies which are held together by large forces, e.g, splitting timber

M.A.= slant height of wedge/thickness of wedge.

Hence a long thin wedge has a higher mechanical advantage than a short thick one; or the smaller the angle theta between the slant heights, the greater the mechanical advantage.

You might be interested in

1) draw a simple circuit with a voltage source and four resistors wired in series

Norma-Jean [14]

Answer:

In this circuit (see attachment #1), we have:

- A voltage source: in this case, we choose a battery. A voltage source is a device producing an electromotive force (in a battery, this is done by means of a chemical reaction), which is responsible for "pushing" the electrons along the circuit and creating a current. The electromotive force (emf) of the battery is also called voltage, and it is indicated with the letter V.

- Four resistors: a resistor is a device which opposes to the flow of current. The property that describes by "how much" the resistor "opposes" to the flow of current is called "resistance", and it is indicated with the letter R.

- In this circuit, the 4 resistors are in series. Resistors are said to be in series when they are connected along the same branch of the circuit, so that the same current flow across each of them.

- For resistors in series, the equivalent resistance of the circuit is given by the sum of the individual resistances:

$R=R_1+R_2+...+R_n$

In this circuit (see attachment #2), we have:

- A voltage source: as before, we have chosen a battery, providing an electromotive force to the circuit

- Three resistors wired in parallel. Resistors are said to be connected in parallel when they are connected along different branches, but with their terminals connected to the same point, so that each of them has the same potential difference across it.

- For resistors in parallel, the equivalent resistance of the circuit is calculated using the formula:

$\frac{1}{R}=\frac{1}{R_1}+\frac{1}{R_2}+...+\frac{1}{R_n}$

In this circuit (see attachment #3), we have:

- A voltage source (again, we have choosen a battery)

- Three resistors, of which:

-- 2 of them are connected in parallel with each other

-- the 3rd one it is in series with the first two

If we call $R_1,R_2$ the resistances of the first 2 resistors in parallel, their equivalent resistance is:

$\frac{1}{R_{12}}=\frac{1}{R_1}+\frac{1}{R_2}\\\rightarrow R_{12}=\frac{R_1 R_2}{R_1+R_2}$

Then, these two resistors are connected in series with resistor $R_3$ ; and so, the total resistance of this circuit will be:

$R=R_{12}+R_3=\frac{R_1R_2}{R_1+R_2}+R_3=\frac{R_1R_2+R_3(R_1+R_2)}{R_1+R_2}$

In this circuit (see attachment #4), we have:

- A voltage source (again, a battery)

- We have 6 resistors, which are arranged as follows:

-- Two branches each containing 3 resistors

-- The two branches are in parallel with each other

So, the total resistance of the two branches are:

$R_{123}=R_1+R_2+R_3$

$R_{456}=R_4+R_5+R_6$

And since the two branches are in parallel, their total resistance will be:

$\frac{1}{R}=\frac{1}{R_{123}}+\frac{1}{R_{456}}\\\rightarrow R=\frac{R_{123}R_{456}}{R_{123}+R_{456}}=\frac{(R_1+R_2+R_3)(R_4+R_5+R_6)}{R_1+R_2+R_3+R_4+R_5+R_6}$

4 0

3 years ago

What is the wavelength of a wave?

PIT_PIT [208]

I know for a fact the answer is D. the distance traveled by the wave during one full cycle

6 0

3 years ago

Read 2 more answers

Can any ideal gas power cycle have a thermal efficiency greater than 55 percent when using thermal energy reservoirs at 627∘C at

Yanka [14]

Answer:

Since the maximum thermal efficiency is higher than 55 percent, there can be a power cycle with these reservoir temperature with an efficiency higher than 55 percent.

Explanation:

The maximum thermal efficiency is determined from the given temperature

nth Carnot = 1- TL/TH

Where TL= 17+273= 290k

TH= 627*273= 900K.

nth Carnot = 1- 290/900 = 0.68

0.68*100 = 68 percent

8 0

3 years ago

A rubber band has a spring constant of 45 N/m. A classmate stretches it a length of 0.2 m before firing it at Mr. C. Ouch. Calcu

nata0808 [166]

Answer:

<h2>0.9 Joules</h2>

Explanation:

Elastic potential energy of a spring= 1/2 × Spring constant × displacement²

following calculations you will get ur answer!!

5 0

3 years ago

A baseball is thrown at a 28° angle and an initial velocity of 70 m/s. Assume no air resistance. How far did the ball travel hor

Genrish500 [490]

Answer:

414.9 m

Explanation:

First, become familiar with the horizontal, and vertical vector components.

Vertical vector: Vy = V × sin (θ).

Horizontal vector: Vx = V × cos(θ).

Distance traveled = Velocity vector × time in the air.

Time in the air given Vy = 2 × Vy / g (in respect to the metric of the vector).

Range of the projectile = Vx² / g

Time in the air given Vx = (Vx + √(Vx)² + 2gh) / g.

Given a 28° angle with an initial velocity of 70m/s, we have enough information to calculate!

Vx = 70 m/s × cos(28°) ≈ 61.806 m/s

Vy = 70 m/s × sin(28°) ≈ 32.863 m/s

t = 2 × Vy / g

t = 2 × ≈32.863 / 9.8

t = ≈65.726 / 9.8

t ≈ 6.7 s

Distance traveled (horizontal) = Vx × t = 61.806 × 6.7 ≈ 414.9 m

6 0
