Answer:Taking as a basis of calculation 100 mol of gas leaving the conversion reactor, draw andcompletely label a flowchart of this process. Then calculate the moles of fresh methanol feed,formaldehyde product solution, recycled methanol, and absorber off-gas, the kg of steamgenerated in the waste-heat boiler, and the kg of cooling water fed to the heat exchangerbetween the waste-heat boiler and the absorber. Finally, calculate the heat (kJ) that must beremoved in the distillation column overhead condenser, assuming that methanol enters as asaturated vapor at 1 atm and leaves as a saturated liquid at the same pressure.
1
SEE ANSWER
Explanation:
Answer:
- Driving surface area as subject to differential pressures
- How to achieve continuous rotation
- Mechanical connections
Explanation:
The general stages of thinking when designing a system are;
- First understanding the problem that requires you to design a solution
- Defining the problem that needs to be solved. In this case is to design an efficient hydraulic engine for a motorboat
- Research to find any available solutions for similar problems
- Idea of the solution
- A prototype to try solve the challenge
- Selecting and adjusting the prototype as you implement the solution.
For a hydraulic engine design, the following designing parts are vital;
- Driving surface area as subject to differential pressures
- How to achieve continuous rotation
- Mechanical connection
Pressures are important due to motor displacements. Fuel burns in the cylinder to cause power through fuel gases burning and expansion which is the four-stroke cycle. Continuous rotation will come in the design considerations through reciprocating motions of pistons into rotary motions. Mechanical connections are vital especially in crank shaft turns, gear box that turns horizontal motions to spinning motions and finally the propeller that drives the boat on the water.
all 4 apply all these are saftey hazards and must be taken as such anything in a work enviorment should be taken seriously and such as hazard
Answer:
[012] :
Here x component is zero. That is why this is in y- z plane
[721] :
This is in all three plane .It means it is in space.
[110] :
Here z component is zero.
That is why this is in x -y plane
From the cubic unit directions we can easily understand all given directions [012], [721], [110].
Answer:
(a) Increases
(b) Increases
(c) Increases
(d) Increases
(e) Decreases
Explanation:
The tensile modulus of a semi-crystalline polymer depends on the given factors as:
(a) Molecular Weight:
It increases with the increase in the molecular weight of the polymer.
(b) Degree of crystallinity:
Tensile strength of the semi-crystalline polymer increases with the increase in the degree of crystallinity of the polymer.
(c) Deformation by drawing:
The deformation by drawing in the polymer results in the finely oriented chain structure of the polymer with the greater inter chain secondary bonding structure resulting in the increase in the tensile strength of the polymer.
(d) Annealing of an undeformed material:
This also results in an increase in the tensile strength of the material.
(e) Annealing of a drawn material:
A semi crystalline material which is drawn when annealed results in the decreased tensile strength of the material.
