Light that bounces off of a wall or ceiling is referred to as

Calculate the mean piston speed, bmep, and specific power of: (a) the spark-ignition engines in Figs. 1.11 and 1.13 at their max

Kisachek [45]

Answer:

Explanation:

See the attached picture for detailed answer.

5 0

4 years ago

It is desired to obtain 500 VAR reactive power from 230 Vrms 50 Hz 1.5 KVAR reactor. What should be the angle of the AC to AC co

OLEGan [10]

Answer:

14.5° ; THD % = 3.873 × 100 = 387.3%.

Explanation:

Okay, in this question we are given the following parameters or data or information which is going to assist us in solving the question efficiently and they are;

(1). "500 VAR reactive power from 230 Vrms 50 Hz 1.5 KVAR reactor".

(2). Consideration of up to 12th harmonic.

So, let us delve right into the solution to the question above;

Step one: Calculate the Irms and Irms(12th) by using the formula for the equation below;

Irms = reactive power /Vrms = 500/230 = 2.174 A.

Irms(12th) = 1.5 × 10^3/ 12 × 230 = 0.543 A.

Step two: Calculate the THD.

Before the Calculation of the THD, there is the need to determine the value for the dissociation factor, h.

h = Irms(12th)/Irms = 0.543/ 2.174 = 0.25.

Thus, THD = [1/ (h)^2 - 1 ] ^1/2. = 3.873.

THD % = 3.873 × 100 = 387.3%.

Step four: angle AC - Ac converter

theta = sin^-1 (1.5 × 10^3/ 12 × 500) = 14.5°.

6 0

3 years ago

Importance of tillage

Tasya [4]

Tillage can result in the degradation of soil, water, and air quality. Of all farm management practices, tillage may have the greatest impact on the environment. A wide variety of tillage equipment, practices and systems are available to farmers, providing opportunities to enhance environmental performance.

6 0

3 years ago

A particle, originally at rest and located at point (3 ft, 2 ft, 5 ft), is subjected to an acceleration a = {6ti + 12t^2k} ft/s^

Sindrei [870]

Answer:

The particle's position at t = 2 is

r = (11ft, 2ft, 21ft) = (11, 2, 21) ft

Explanation:

r₀ = (3, 2, 5) ft

a = (6t, 0, 12t²) ft/s²

a = dv/dt

dv/dt = (6tî + 0j + 12t²ķ)

dv = (6tî + 0j + 12t²ķ) st

Integrating the left hand side from 0 to v (the particle was originally at rest) and the right hand side from 0 to t,

We obtain,

v = (3t²î + 0j + 4t³ķ) ft/s

v = dr/dt

dr/dt = (3t²î + 0j + 4t³ķ)

dr = (3t²î + 0j + 4t³ķ) st

Integrating the left hand side from r₀ (the original position) to r and the right hand side from 0 to t,

r - r₀ = (t³î + 0j + t⁴ķ) ft

r = (t³î + 0j + t⁴ķ) + r₀

r = (t³î + 0j + t⁴ķ) + (3î + 2j + 5ķ)

At t=2s, t³ = 8 and t⁴ = 16

r = (8î + 0j + 16ķ) + (3î + 2j + 5ķ)

r = (11î + 2j + 21ķ) ft

r = (11ft, 2ft, 21ft)

Hope this helps!

4 0

3 years ago

प्रहार का समरूपी भिन्नार्थक शब्द अर्थ के साथ

Reika [66]

Answer:

uhvdiuuauivhsifuhviudshivuhrwwwwwgyuvrrrrrrvuybgdwdoushduhsfuhdsiufhduisfhsofhuaifhuadsihfuiahfuidhsfiuhdsiufhdsaigsdygfewyihfiewbvhwegfiyerrrgqewfygediyfgdsyifguysdgfyuuaegfuyaeggfuyegwfyugewafuyegwiufggeegfyusdggfsgodqwufyew98fyyy79ewyf7eywf8777etf87tewtf

Explanation:

djhidhfdiushfiudshfui

3 0

3 years ago

Light that bounces off of a wall or ceiling is referred to as_
