Answer:
x = 45 cm
Explanation:
Given that,
The length of a rod, L = 50 cm
Mass, m₁ = 0.2 kg
It is at 40cm from the left end of the rod.
We need to find the distance from the left end of the rod should a 0.6kg mass be hung to balance the rod.
The centre of mass of the rod is at 25 cm.
Taking moments of both masses such that,
The distance from the left end is 40+5 = 45 cm.
Hence, at a distance of 45 cm from the left end it will balance the rod.
Answer:
(a). Check attachment.
(b). 280.305 J.
(c). 31.81 kpa; 38.26K.
(d). 24.05K.
(e). 24.05k; 40kpa.
(f). -138.6J.
Explanation:
(a). Kindly check the attached picture for the diagram showing the four process.
1 - 2 = adiabatic expansion process.
2 - 3 = Isochoric process.
3 - 4 = isothermal process.
4 - 1 = isochoric process.
(b). Recall that the process from 1 to is an adiabatic expansion process.
NB: b = 5/3 for a monoatomic gas.
Then, the workdone = (1/ 1 - 1.66) [ (p1 × v1^b)/ v2^b × v2 - (p1 × v1)].
= ( 1/ 1 - 5/3) [ (101 × 5^5/3) × 10^1 -5/3] - 101 × 5.
Thus, the workdone = 280.305 J.
(c). P2 = P1 × V1^b/ V2^b = 101 × 5^5/3/ 10^5/3 = 31.81 kpa.
T2 = P2 × V2/ R × 1 = 31.81 × 10/ 8.324 = 38.36k.
(d). The process 2 - 3 is an Isochoric process, then;
T3 = T2/P2 × P3 = 38.26/ 31.82 × 20 = 24.05K.
(e). The process 3 - 4 Is an isothermal process. Then, the temperature at 4 will be the same temperature at 3. Tus, we have the temperature; point 3 = point 4 = 24.05k.
The pressure can be determine as below;
P4 = P3 × V3/ V4 = 20 × 10/ 5 = 200/ 5 = 40 kpa.
(f) workdone = xRT ln( v4/v3) = 1 × 8.314 × 24.05 × ln (5/10) = - 138.6 J
