In your new role at Wayne Industries, you have been given the freedom to propose and develop your own project ideas. You have an
idea for a frictionless piston-cylinder assembly. Your design requires the expansion of 0.25 m3 of air at 3.3 MPa and 280 oC to 180 kPa in a slow, isothermal process. In order to be approved for further development, you need to submit calculations for the values of the heat transferred in the process.
1 answer:
You might be interested in
Answer:
a) see attachment
b) A= m0m1+ m1m2+ m0m2
see attachment for K-map
c) see attachment
Explanation:
a) see attachment for truth table
b) see attachment for k-map
A= m0m1+ m1m2+ m0m2
c) see attachment for gate level circuit
