Consider a vacuum-filled parallel plate capacitor (no dielectric material between the plates). What is the ratio of conduction c
urrent Jc to displacement current Jd at 10 MHz
1 answer:
Answer: 1798
Explanation:
Given that there is no dielectric material between the plates,
the permittivity of free space = 9 × 10^-12 f/m
The frequency F = 10 MHz
The ratio of conduction current JC to the displacement current Jd is also known as loss tangent.
Please find the attached file for the solution
