I need help, I’m completely lost.

Suppose that you are holding a pencil balanced on its point. If you release the pencil and it begins to fall, what will be the a

Naily [24]

Answer:

The angular acceleration of the pencil α = 17 rad·s⁻²

Explanation:

Using Newton's second angular law or torque to find angular acceleration, we get the following expressions:

τ = I α (1)

W r = I α (2)

The weight is that the pencil has is,

sin 10 = r / (L/2)

r = L/2(sin(10))

The shape of the pencil can be approximated to be a cylinder that rotates on one end and therefore its moment of inertia will be:

I = 1/3 M L²

Thus,

mg(L / 2)sin(10) = (1/3 m L²)(α)

α(f) = 3/2(g) / Lsin(10)

α = 3/2(9.8) / 0.150sin(10)

α = 17 rad·s⁻²

Therefore, the angular acceleration of the pencil is 17 rad·s⁻²

3 0

3 years ago

Which one of the following explains how light energy helps us see all kinds of objects around us?

vampirchik [111]

Answer:

light reflects off the objects and enter our eyes

6 0

3 years ago

Astronauts measure their mass by measuring the period of oscillation when sitting in a chair connected to a spring. The Body Mas

anzhelika [568]

Answer:

55 kg

Explanation:

spring constant (k) = 600 N/m

mass of chair (Mc) = 12 kg

period of oscillation of chair and man (T) = 2.1 s

what is the mass of the astronaut (Ma) ?

mass of the astronaut (Ma) = total mass (Mt) - mass of chair (Mc)

where

total mass (Mt) = $\frac{T^{2}}{4π^{2}}k$

taking π as 3.142

total mass (Mt) = $\frac{2.1^{2}}{4 x 3.142^{2}}600$

total mass (Mt) = 67 kg

therefore

mass of astronaut = 67 - 12 = 55 kg

4 0

4 years ago

. A new game has been invented where the player has to combine a dive from a board with shooting of a basketball through a hoop

skad [1K]

Explanation:

Not being able to see the picture attached and supposing the ground level is considered to be the water level so to be able to find out the velocity you need to score into the hoop you need to use the combined force ( resulting force) to throw the ball at 6.50 m distance, 1 m below to where you are standing

5 0

3 years ago

Read 2 more answers

Assume you need to design a hydronic system that can deliver 80,000 Btu/hr. What flow rate of water is required if the temperatu

PolarNik [594]

Answer:

At 10°F change in temperature

Mass flowrate = 1.01 kg/s = 2.227 lbm/s

Volumetric flowrate = 1010 m³/s = 35667.8 ft³/s

At 20°F change in temperature

Mass flowrate = 0.505 kg/s = 1.113 lbm/s

Volumetric flowrate = 505 m³/s = 17833.9 ft³/s

Explanation:

80000 btu/hr = 23445.7 W

P = ṁc(ΔT)

ṁ = MASS flowrate

c = specific heat capacity of water = 4182 J/kg.K,

ΔT = change in temperature = 10°F

To convert, a change of 18°F is equal to a change of 10°C

A change of 10°F = 10×10/18 = 5.556°C = 5.556K

P = ṁc(ΔT)

23445.7 = ṁ(4182 × 5.556)

ṁ = 23445.7/(4182 × 5.556)

ṁ = 1.01 kg/s = 2.227 lbm/s

In volumetric flow rate, Q = density × mass flowrate = 1000 × 1.01 = 1010 m³/s = 35667.8 ft³/s

For a change of 20°F,

ΔT = change in temperature = 20°F

To convert, a change of 18°F is equal to a change of 10°C

A change of 20°F = 20×10/18 = 11.1111°C = 11.111K

P = ṁc(ΔT)

23445.7 = ṁ(4182 × 11.111)

ṁ = 23445.7/(4182 × 11.111)

ṁ = 0.505 kg/s = 1.113 lbm/s

In volumetric flow rate, Q = density × mass flowrate = 1000 × 0.505 = 505 m³/s = 17833.9 ft³/s

Hope this Helps!!!

4 0

4 years ago
