Answer:
sampling distribution
Explanation:
Sampling distribution is distribution of multiple samples' satistics of a population.
The relationship between resistance and the area of the cross section of a wire is inversely proportional . When resistance is increased in a circuit , for example by adding more electrical components , the current decreases as a result.
Answer:
a) V =10¹¹*(1.5q₁ + 3q₂)
b) U = 1.34*10¹¹q₁q₂
Explanation:
Given
x₁ = 6 cm
y₁ = 0 cm
x₂ = 0 cm
y₂ = 3 cm
q₁ = unknown value in Coulomb
q₂ = unknown value in Coulomb
A) V₁ = Kq₁/r₁
where r₁ = √((6-0)²+(0-0)²)cm = 6 cm = 0.06 m
V₁ = 9*10⁹q₁/(0.06) = 1.5*10¹¹q₁
V₂ = Kq₂/r₂
where r₂ = √((0-0)²+(3-0)²)cm = 3 cm = 0.03 m
V₂ = 9*10⁹q₂/(0.03) = 3*10¹¹q₂
The electric potential due to the two charges at the origin is
V = ∑Vi = V₁ + V₂ = 1.5*10¹¹q₁ + 3*10¹¹q₂ = 10¹¹*(1.5q₁ + 3q₂)
B) The electric potential energy associated with the system, relative to their infinite initial positions, can be obtained as follows
U = Kq₁q₂/r₁₂
where
r₁₂ = √((0-6)²+(3-0)²)cm = √45 cm = 3√5 cm = (3√5/100) m
then
U = 9*10⁹q₁q₂/(3√5/100)
⇒ U = 1.34*10¹¹q₁q₂
Answer:
D. Both pull-in and hold-in windings are energized.
Explanation:
The instant the ignition switch is turned to the start position, "Both pull-in and hold-in windings are energized." This is because the moment the ignition switch is turned to the start position, voltage passes through to the S terminal of the solenoid.
The hold-in winding is attached to the case of the solenoid. Similarly, the pull-in winding is also attached to the starter motor. Thereby, the current will move across both windings by getting energized to generate a strong magnetic field.
