Question

A 129-kg horizontal platform is a uniform disk of radius 1.61 m and can rotate about the vertical axis through its center. A 65.7-kg person stands on the platform at a distance of 1.07 m from the center and a 27.3-kg dog sits on the platform near the person, 1.31 m from the center. Find the moment of inertia of this system, consisting of the platform and its population, with respect to the axis.

Answer 1

Answer:

Moment of inertia of the system is 289.088 kg.m^2

Explanation:

Given:

Mass of the platform which is a uniform disk = 129 kg

Radius of the disk rotating about vertical axis = 1.61 m

Mass of the person  standing on platform = 65.7 kg

Distance from the center of platform = 1.07 m

Mass of the dog on the platform = 27.3 kg

Distance from center of platform = 1.31 m

We have to calculate the moment of inertia.

Formula:

MOI of disk = $\frac{MR^2}{2}$

Moment of inertia of the person and the dog will be mr^2.

Where m and r are different for both the bodies.

So,

Moment of inertia $(I_y_y )$  of the system with respect to the axis yy.

⇒ $I_y_y=I_d_i_s_k + I_m_a_n+I_d_o_g$

⇒ $I_y_y=\frac{M_d_i_s_k(R_d_i_s_k)^2}{2} +M_m(r_c)^2+M_d_o_g(R_c)^2$

⇒ $I_y_y=\frac{129(1.61)^2}{2} +65.7(1.07)^2+27.2(1.31)^2$

⇒ $I_y_y=289.088\ kg.m^2$

The moment of inertia of the system is 289.088 kg.m^2
