Answer:
168 Hz, 280 Hz and 392 Hz
Explanation:
The resonant frequencies for a closed pipe at one end is given by :
, n = 1,3,5...
The fundamental frequency, f₁ = v/4l = 56 Hz
For first overtone, put n = 3
For second overtone, put n = 5
For third overtone, put n = 7
So, the first three overtones are 168 Hz, 280 Hz and 392 Hz.
Answer:
v = 2 m/s
Explanation:
The object moves 20 m in 10 s initially. Then it remains at rest for 20 s. It is required to find the average speed of the object.
Fro 10 s it covers 20 m. For that time, speed is :
For 20 s, it was at rest means distance covered is 0. So, speed is 0.
The average speed of the object is equal to the sum of speed for 10 s and for 20 s i.e.
v = 2 m/s + 0 = 2 m/s
So, the average speed of the object is 2 m/s.
Answer:
Option b. Dark spot
Explanation:
Michelson interferometer gives the path difference of the light as path difference, d as twice the distance moved or covered by the mirror , x and is given as:
d= 2x
Since, its an even multiple, we obtain a bright fringe
now, when the move half the distance, i.e.,
Therefore, the path difference for half the distance is:
d = x
As it is clear that its an odd multiple which correspond to dark spot as the final image
